Abstract

In a motor current optimization control method and system, while the motor runs steadily at a set speed, one d-axis current command value of the input current is set to 0. Then, the d-axis current command value is step-wisely increased by an increment at least twice. At least three real-time feedback current values can be collected from detecting a feedback current of an AC power. When an instant detected is smaller than the previous detected, the d-axis current command value is increased. When the instant detected is greater than the previous detected, the d-axis current command value corresponding to the previous detected is a minimum feedback current value and is defined as the optimized d-axis current command value. The optimized d-axis current command value is set as the d-axis current command value of the input current to control the motor to keep running steadily at the set speed.

IPC Classes  ?

• H02P 21/00 - Arrangements or methods for the control of electric machines by vector control, e.g. by control of field orientation
• H02P 21/22 - Current control, e.g. using a current control loop

Abstract

A cooling motor includes a motor device having a motor casing, a motor assembly arranged in the motor casing, and a centrifugal fan, and a cooling device having first and second cooling components. The first cooling component includes a first cold plate jacket and a first heat circulation pipeline. The first cold plate jacket is sleeved on the motor assembly and thermally connected to a stator, and the first cold plate jacket includes first cold plates. The first thermal circulation pipeline filled with a first working fluid passes through the first cold plate jacket. The second cooling component includes a second cold plate jacket and a second heat circulation pipeline. The second cold plate jacket, sleeving the first cold plate jacket in an insulation manner, includes second cold plates and cooling fins. The second thermal circulation pipeline filled with a second working fluid passes through the second cold plate jacket.

IPC Classes  ?

• H02K 9/20 - Arrangements for cooling or ventilating for machines with closed casing and closed-circuit cooling using a liquid cooling medium, e.g. oil wherein the cooling medium vaporises within the machine casing
• H02K 5/20 - Casings or enclosures characterised by the shape, form or construction thereof with channels or ducts for flow of cooling medium
• H02K 9/22 - Arrangements for cooling or ventilating by solid heat conducting material embedded in, or arranged in contact with, the stator or rotor, e.g. heat bridges

Abstract

In various embodiments, a mobile, open-air, electrical skid may provide electrical power from high voltage power lines via one or more electrical components to natural gas compressors at a natural gas compressor site. In several embodiments, the open-air skid may be of a size that can fit on a flat-bed trailer so that the skid can be transported to the site, and the open-air skid may not have side walls to allow for air flowing across the components. The electrical components may include an electric variable frequency drive, a sync reactor, one or more motor relays, an input cabinet, one or more motor control cabinets, a remote cooling unit, and/or other electrical components utilized to start-up one or more natural gas compressors and keep the one or more natural gas compressors running.

IPC Classes  ?

• F17D 1/07 - Arrangements for producing propulsion of gases or vapours by compression
• F04B 35/04 - Piston pumps specially adapted for elastic fluids and characterised by the driving means to their working members, or by combination with, or adaptation to, specific driving engines or motors, not otherwise provided for the means being electric
• F04B 39/12 - CasingsCylindersCylinder headsFluid connections

Abstract

In various embodiments, a mobile, open-air, electrical skid may provide electrical power from high voltage power lines via one or more electrical components to natural gas compressors at a natural gas compressor site. In several embodiments, the open-air skid may be of a size that can fit on a flat-bed trailer so that the skid can be transported to the site, and the open-air skid may not have side walls to allow for air flowing across the components. The electrical components may include an electric variable frequency drive, a sync reactor, one or more motor relays, an input cabinet, one or more motor control cabinets, a remote cooling unit, and/or other electrical components utilized to start-up one or more natural gas compressors and keep the one or more natural gas compressors running.

IPC Classes  ?

• F16M 3/00 - Portable or wheeled frames or beds, e.g. for emergency power-supply aggregates, compressor sets
• F04D 25/06 - Units comprising pumps and their driving means the pump being electrically driven
• F04B 17/06 - Mobile combinations
• F01B 27/00 - Starting of machines or engines
• H02P 1/16 - Arrangements for starting electric motors or dynamo-electric converters for starting dynamo-electric motors or dynamo-electric converters
• F04B 17/03 - Pumps characterised by combination with, or adaptation to, specific driving engines or motors driven by electric motors
• F04B 35/06 - Mobile combinations
• F04B 35/04 - Piston pumps specially adapted for elastic fluids and characterised by the driving means to their working members, or by combination with, or adaptation to, specific driving engines or motors, not otherwise provided for the means being electric
• F01B 23/08 - Adaptations for driving, or combinations with, pumps

Abstract

Permanent magnets using high temperature superconductor tapes are disclosed. For example, a magnet may include a superconductor tape having two ends, a slit in the superconductor tape between the two ends that forms two legs, a separation between the legs that forms a loop, and a trapped magnetic field in the superconductor tape.

IPC Classes  ?

• H10N 60/83 - Element shape

Abstract

In a refrigerator storage temperature control method, according to a target temperature (Ts), a regulated temperature upper limit value (T1) and an allowable temperature upper limit value (T2) are defined. According to T1 and T2, an adjustment interval, an allowable temperature interval and a convergent cooling interval are defined. A detection temperature is periodically detected and updated with a detection period, the detection temperature in the previous detection period is a previous temperature, and the detection temperature in the instant detection period is a current temperature. A control module performs RPS-m for a compressor when the current temperature falls within the adjustment interval, RPS+0 when the current temperature falls within the allowable temperature interval, and RPS+o when the current and previous temperatures fall within the convergent cooling interval and the allowable temperature interval, respectively. Detection, judgment and control are repeated until the current temperature falls within the allowable temperature interval.

IPC Classes  ?

• F25D 29/00 - Arrangement or mounting of control or safety devices
• G05B 15/02 - Systems controlled by a computer electric

Goods & Services

Electrical power skid assembly for providing power to electrically driven motors for natural gas pumps and compressors, pipelines, and fans comprised of variable frequency drives for motors, other than for land vehicles, step down transformer, motor control center being electric control panels, electrical power distribution units, and electric control devices, all mounted on a prefabricated metal platform and sold as a unit

Abstract

A horizontal assembly method for permanent magnet motor is mainly to firstly dispose the first bracket and the second bracket on the motor assembly platform, then fix the stator assembly on the sliding carrier so as to move with the sliding carrier to sleeve over the fixed thimble to engage the first bracket, then position the rotor assembly between the fixed thimble and the movable thimble so as to fix the rotor assembly by the protruding movable thimble, then control the sliding carrier to assemble the stator assembly and the first bracket to the rotor assembly so that the one end of the rotational shaft can be supported by the first bracket, and finally assemble the second bracket to the stator assembly so as to support another end of the rotational shaft. Thereupon, the permanent magnet motor can be produced.

IPC Classes  ?

• H02K 15/00 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines

Abstract

Permanent magnets using high temperature superconductor tapes are disclosed. For example, a magnet may include a superconductor tape having two ends, a slit in the superconductor tape between the two ends that forms two legs, a separation between the legs that forms a loop, and a trapped magnetic field in the superconductor tape.

Abstract

A rotor including: a drive shaft rotating about an axis of rotation, a plurality of annular rotor plates, identical to each other, mounted on the drive shaft, superposed along the axis of rotation and including a plurality of openings, a pair of closing plates which are located at the ends of said plurality of rotor plates, a plurality of bars, passing through at least part of said plurality of openings of the plurality di rotor plates, a pair of short-circuit rings located a the ends of said plurality of bars and wherein an active ratio between a first area occupied by the plurality of openings and a total area of the rotor plate is greater than or equal to 0.30, that is, R1=A1/AT≥0.30.

IPC Classes  ?

• H02K 19/14 - Synchronous motors having additional short-circuited windings for starting as asynchronous motors
• H02K 19/10 - Synchronous motors for multi-phase current

Goods & Services

Speed reducers other than for land vehicles; gear speed reducers; gear motors other than for land vehicles.

Goods & Services

machine parts, namely, Speed reducers other than for land vehicles; machine parts, namely, gear speed reducers; gear motors other than for land vehicles

Abstract

A rotor structure includes a rotor body and a plurality of magnets. The rotor body has a plurality of surrounding magnet-setting areas, and each magnet setting area has a first magnet slot and a second magnet slot symmetrically arranged to a centripetal axis. A first outer end of the first magnet slot and a second outer end of the second magnet slot are close to the centripetal axis and rotor's outer edge. A first outer end of the first magnet slot and a second outer end of the second magnet slot are distant to the centripetal axis and rotor's outer edge. The outer edge has a plurality of notches intersected by the corresponding centripetal axes. The magnets are respectively fixed to the first magnet slots and the second magnet slots of the magnet-setting areas.

IPC Classes  ?

• H02K 1/27 - Rotor cores with permanent magnets
• H02K 1/278 - Surface mounted magnetsInset magnets

Goods & Services

Speed reducers (not for land vehicles); Speed reducers with gears; Gear motors other than for land vehicles.

Goods & Services

Speed reducers (not for land vehicles); Speed reducers with gears; Gear motors other than for land vehicles.

Abstract

An apparatus for assembling a permanent magnet motor rotor includes a first-end positioning assembly, a plurality of connectors, and a second-end positioning assembly. The first-end positioning assembly is utilized to fix a first-end rotor core. The second-end positioning assembly is utilized to fix a second-end rotor core. The connectors are utilized to connect and fix the first-end positioning assembly with the second-end positioning assembly. Each first longitudinal axis of each first positioning element of the first end positioning assembly is different from each second longitudinal axis of each second positioning element of the second end positioning assembly. In addition, a method for assembling a permanent magnet motor rotor is also provided.

IPC Classes  ?

• H02K 15/02 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies
• H02K 15/03 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies having permanent magnets
• H02K 1/27 - Rotor cores with permanent magnets

Abstract

An automated guided vehicle control system includes a commodity database, a historical shopping information acquisition module, a purchase-item prediction module, an automated guided vehicle database, an automated guided vehicle dispatch demand assessment module and an automated guided vehicle dispatch module. The historical shopping information acquisition module is utilized to retrieve the historical shopping information related to the customer, further to locate the instant predicted commodity to be purchased, and thereby to dispatch the suitable automated guided vehicle to the waiting area of the customer. Further, the historical shopping information is evaluated to provide the commodity type options for the customer to select, to locate the commodity type to be purchased, and thereby to organize the automated navigation path for the automated guided vehicle to travel along to reach the assigned commodity display area.

IPC Classes  ?

• B60W 10/00 - Conjoint control of vehicle sub-units of different type or different function
• B60W 50/00 - Details of control systems for road vehicle drive control not related to the control of a particular sub-unit
• B60W 60/00 - Drive control systems specially adapted for autonomous road vehicles
• G01C 21/20 - Instruments for performing navigational calculations
• G06Q 10/0631 - Resource planning, allocation, distributing or scheduling for enterprises or organisations
• G06Q 10/087 - Inventory or stock management, e.g. order filling, procurement or balancing against orders
• G06Q 20/20 - Point-of-sale [POS] network systems
• G06Q 30/0202 - Market predictions or forecasting for commercial activities
• G06Q 30/0601 - Electronic shopping [e-shopping]
• G07C 9/00 - Individual registration on entry or exit

Abstract

A method includes: forming a sand core including a main portion and core-head members connecting the main portion; applying a casting process to produce a frame casting having a first end, a first-end inner wall, a second end, a second-end inner wall, a closed water channel between the first-end inner wall and the second-end inner wall, a water inlet, a water outlet and sand-expelling holes at the first end; shaking the frame casting to have part of the sand core to leave the closed water channel via the water inlet, the water outlet and the sand-expelling holes; pressurizing a fluid into the closed water channel via the water inlet to carry the rest of the sand core to leave the closed water channel via the sand-expelling holes and the water outlet; and applying screw bolts to lock the sand-expelling holes to manufacture a closed-type liquid-cooling motor frame.

IPC Classes  ?

• H02K 15/00 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines
• H02K 15/14 - CasingsEnclosuresSupports
• H02K 15/02 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies
• B22D 19/00 - Casting in, on, or around, objects which form part of the product
• H02K 9/19 - Arrangements for cooling or ventilating for machines with closed casing and closed-circuit cooling using a liquid cooling medium, e.g. oil

Abstract

A mobile device includes a mobile platform, a spray generating assembly, an ultraviolet light-emitting module, a scanning module and a controlling module. The spray generating assembly is to generate a disinfecting and sterilizing spray for a spraying, disinfecting and sterilizing operation in the working area. The ultraviolet light-emitting module is configured to generate ultraviolet beams for performing a radiating, disinfecting and sterilizing operation onto a ground surface of the working area. The scanning module defined with an entire scan range is configured to generate a warning signal upon a human in the entire scan range. The controlling module, electrically connected with the scanning module and the spray generating assembly, is configured to control the spray generating assembly to stop generating the disinfecting and sterilizing sprays upon receiving the warning signal, so as to prevent the human from inhaling excessive sprays.

IPC Classes  ?

• A61L 2/24 - Apparatus using programmed or automatic operation
• A61L 2/10 - Ultraviolet radiation
• A61L 2/22 - Phase substances, e.g. smokes, aerosols
• G05D 1/00 - Control of position, course, altitude or attitude of land, water, air or space vehicles, e.g. using automatic pilots
• G05D 1/10 - Simultaneous control of position or course in three dimensions

Abstract

Described is a rotor (1) comprising: a drive shaft (2) rotating about an axis of rotation (X), a plurality of annular rotor plates (3), identical to each other, mounted on the drive shaft (2), superposed along the axis of rotation (X) and comprising a plurality of openings (41, 42), a pair of closing plates (52, 53) which are located at the ends of said plurality of rotor plates (3), a plurality of bars (51), passing through at least part of said plurality of openings (41, 42) of the plurality of rotor plates (3), a pair of short-circuit rings (55) located at the ends of said plurality of bars (51) and wherein an active ratio (R1) between a first area (A1) occupied by the plurality of openings (41, 42) and a total area (AT) of the rotor plate (3) is greater than or equal to 0.30, that is, R1=A1/AT ≥ 0.30.

IPC Classes  ?

• H02K 1/24 - Rotor cores with salient poles
• H02K 19/10 - Synchronous motors for multi-phase current

Abstract

A recovery system is provided to recover energy from heat. In an embodiment, the system includes an evaporator to receive a flow of natural gas at a first temperature and output the flow at a second, lower temperature. The evaporator may receive a flow of cooling media to cool the natural gas and output a flow of heated cooling media. The system may further include: a heat-to-mechanical energy converter coupled to the evaporator to receive the flow of heated cooling media and to output first cooled cooling media; an induction generator coupled to be driven by the heat-to-mechanical energy converter; a medium voltage drive coupled to receive power from the induction generator and to condition the power for output to an electrical distribution system; and a condenser to condense the first cooled cooling media to provide the flow of cooling media to the evaporator.

IPC Classes  ?

• F25B 27/02 - Machines, plants or systems, using particular sources of energy using waste heat, e.g. from internal-combustion engines
• F25B 1/00 - Compression machines, plants or systems with non-reversible cycle

Abstract

A heat-dissipation frame assembly includes a motor frame, an air-guide shield and an airflow-driving device. The motor frame includes a main frame and annular heat-dissipation fins. Each of the annular heat-dissipation fins has an outer edge, and an average radial distance is defined between the outer edge and the central axis. The average radial distances of the annular heat-dissipation fins are decreased gradually in the longitudinal direction from the first end portion to the second end portion, and an external annular channel is formed between any neighboring two annular heat-dissipation fins. The airflow-driving device, disposed at the second end portion of the main frame, is used for generating at least one heat-dissipating airflow. The air-guide shield, connected with the motor frame, surrounds and covers the plurality of annular heat-dissipation fins, such that the at least one heat-dissipating airflow is guided into the plurality of external annular channels.

IPC Classes  ?

• H02K 5/18 - Casings or enclosures characterised by the shape, form or construction thereof with ribs or fins for improving heat transfer
• H02K 9/04 - Arrangements for cooling or ventilating by ambient air flowing through the machine having means for generating a flow of cooling medium
• H02K 5/20 - Casings or enclosures characterised by the shape, form or construction thereof with channels or ducts for flow of cooling medium

Abstract

A rotor assembly includes a rotor body having two rotor ends, a rotating shaft penetrating the two rotor ends, and two rotor end plates. The two rotor end plates are pressed to fit correspondingly the two rotor ends, and each rotor end plate includes an inner ring structure and an outer ring structure. The inner ring structure, made of an iron-based material and used to sleeve the rotating shaft, has a first outer-ring peripheral surface and a first thickness. The outer ring structure, made of an aluminum-based material, includes a first radial segment and a second radial segment. The first radial segment, wrapping the first outer-ring peripheral surface, has a second outer-ring peripheral surface and a second thickness larger than the first thickness. The second radial segment, wrapping integrally the second outer-ring peripheral surface as a unique piece, has a third thickness larger than the second thickness.

IPC Classes  ?

• H02K 1/27 - Rotor cores with permanent magnets
• H02K 5/16 - Means for supporting bearings, e.g. insulating supports or means for fitting bearings in the bearing-shields
• H02K 5/15 - Mounting arrangements for bearing-shields or end plates

Abstract

A defogging control system includes a plurality of first heating wires, a plurality of second heating wires, an electrical sensor and driver, a timer, an environment sensing module, and a control module. The electrical sensor and driver is utilized to generate a start signal or a stop signal, corresponding to a controller of a refrigeration storage apparatus. The timer is utilized to count a real-time operation time and record a previous operation time. The environment sensing module is utilized to sense a temperature and a humidity. The control module is utilized to control the first heating wires and the second heating wires by the real-time operation time, the previous operation time, the temperature, and the humidity. Further, a defogging control method is also provided.

IPC Classes  ?

• F25B 49/02 - Arrangement or mounting of control or safety devices for compression type machines, plants or systems
• F25D 23/02 - DoorsCovers
• F25D 21/00 - DefrostingPreventing frostingRemoving condensed or defrost water
• F25D 21/04 - Preventing the formation of frost or condensate
• F25D 21/08 - Removing frost by electric heating
• F25B 47/02 - Defrosting cycles
• A47F 3/04 - Showcases or show cabinets air-conditioned, refrigerated

Abstract

An auxiliary positioning system includes a mobile platform and a plurality of reflective stickers. The reflective stickers are disposed in a navigation space. The mobile platform includes a map-establishing module, a positioning module, a laser scan and analysis module, a coordinate-processing module, a comparison module and a calibration module. The map-establishing module is utilized to generate a global map. The positioning module is utilized to locate a position coordinate. The laser scan and analysis module is utilized to scan the navigating space to generate a scan direction and distance vector. The coordinate-processing module is utilized to generate a position direction and distance vector. The comparison module is utilized to compare the scanning coordinate with the mapping coordinate. The calibration module is utilized to calibrate the position coordinate.

IPC Classes  ?

• G01S 17/00 - Systems using the reflection or reradiation of electromagnetic waves other than radio waves, e.g. lidar systems
• G01S 17/74 - Systems using reradiation of electromagnetic waves other than radio waves, e.g. IFF, i.e. identification of friend or foe
• G01S 7/48 - Details of systems according to groups , , of systems according to group

Abstract

An apparatus for assembling a permanent magnet motor rotor includes a first-end positioning assembly, a plurality of connectors, and a second-end positioning assembly. The first-end positioning assembly is utilized to fix a first-end rotor core. The second-end positioning assembly is utilized to fix a second-end rotor core. The connectors are utilized to connect and fix the first-end positioning assembly with the second-end positioning assembly. Each first longitudinal axis of each first positioning element of the first end positioning assembly is different from each second longitudinal axis of each second positioning element of the second end positioning assembly. In addition, a method for assembling a permanent magnet motor rotor is also provided.

IPC Classes  ?

• H02K 15/00 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines
• H02K 15/03 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies having permanent magnets
• H02K 1/27 - Rotor cores with permanent magnets

Abstract

A system is applied for calibrating a map data configured for a mobile platform to generate a calibration map after an impact, and includes a map-generating module, a positioning module, an impact-detecting module, an image-analyzing module, a coordinate-reconstructing module and a map data-calibrating module. The map-generating module generates a global map with a first coordinate system. The positioning module positions a mobile platform before the impact. The impact detecting module generates a reconstructing signal after the impact upon the mobile platform is detected. The image-analyzing module searches and analyzes an image of a feature object. The coordinate-reconstructing module re-establishes a second coordinate system, and the map data-calibrating module calibrates the global map to generate the calibration map after the impact.

IPC Classes  ?

• G06T 7/70 - Determining position or orientation of objects or cameras
• G01C 21/00 - NavigationNavigational instruments not provided for in groups
• G05D 1/02 - Control of position or course in two dimensions
• G05D 1/00 - Control of position, course, altitude or attitude of land, water, air or space vehicles, e.g. using automatic pilots

Goods & Services

Engines for compressors; Elevator motors; Alternating current motors; Electric motors for use with doors; Motors, other than for land vehicles; Sewing machine motors; Gear motors other than for land vehicles; Motors, electric, other than for land vehicles; Electric motors for heating installations; Motors, electric, other than for land vehicles; Motors, electric, other than for land vehicles; Electrical engines, other than for land vehicles; Electric motors, and their parts, not for land vehicles; Electric motors for machines (except for land vehicles).

Abstract

A recovery system is provided to recover energy from heat. In an embodiment, the system includes an evaporator to receive a flow of natural gas at a first temperature and output the flow at a second, lower temperature. The evaporator may receive a flow of cooling media to cool the natural gas and output a flow of heated cooling media. The system may further include: a heat-to-mechanical energy converter coupled to the evaporator to receive the flow of heated cooling media and to output first cooled cooling media; an induction generator coupled to be driven by the heat-to-mechanical energy converter; a medium voltage drive coupled to receive power from the induction generator and to condition the power for output to an electrical distribution system; and a condenser to condense the first cooled cooling media to provide the flow of cooling media to the evaporator.

IPC Classes  ?

• F25B 27/02 - Machines, plants or systems, using particular sources of energy using waste heat, e.g. from internal-combustion engines
• F25B 1/00 - Compression machines, plants or systems with non-reversible cycle

Abstract

In one embodiment, a high speed induction machine includes: a stator formed of a first plurality of laminations having a thickness of less than approximately 0.01 inch and a winding comprising a coil formed of Litz wire adapted about the stator; and a rotor adapted within the stator. The rotor may include: a rotor core formed of a second plurality of laminations having a second thickness of greater than approximately 0.10 inch and formed of high strength steel and sandwiched between a first end region including at least one first peripheral second lamination and a second end region including at least one second peripheral second lamination, the first end region having a first end ring retained by a first retaining ring adapted there around, the second end region having a second end ring retained by a second retaining ring adapted there around.

IPC Classes  ?

• H02K 3/24 - Windings characterised by the conductor shape, form or construction, e.g. with bar conductors with channels or ducts for cooling medium between the conductors
• H02K 1/16 - Stator cores with slots for windings
• H02K 1/26 - Rotor cores with slots for windings
• H02K 1/30 - Means for mounting or fastening rotating magnetic parts on to, or to, the rotor structures using intermediate parts, e.g. spiders
• H02K 3/42 - Means for preventing or reducing eddy-current losses in the winding heads, e.g. by shielding
• H02K 15/02 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies
• H02K 15/12 - Impregnating, moulding insulation, heating or drying of windings, stators, rotors or machines
• H02K 3/12 - Windings characterised by the conductor shape, form or construction, e.g. with bar conductors arranged in slots

Goods & Services

Chemicals for the treatment to improve corrosion resistance. Speed changers. Treatment of metal parts to prevent corrosion.

Abstract

A rotor with a pressure-deviation generating assembly includes a main body having a plurality of tunnels extending longitudinally, a first pressure-deviation generating assembly, and a second pressure-deviation generating assembly. The first pressure-deviation generating assembly generates a plurality of first high-pressure regions and first low-pressure regions. The second pressure-deviation generating assembly generates a plurality of second high-pressure regions and second low-pressure regions. At least one first flow flows through some of the tunnels from the first high-pressure regions to the second low-pressure regions, and at least one second flow flows through the rest of the tunnels from the second high-pressure regions to the first low-pressure regions. Thereupon, a bi-directional air flow pattern inside the tunnels can be built to promote the heat dissipation of the rotor.

IPC Classes  ?

• H02K 1/32 - Rotating parts of the magnetic circuit with channels or ducts for flow of cooling medium
• H02K 9/22 - Arrangements for cooling or ventilating by solid heat conducting material embedded in, or arranged in contact with, the stator or rotor, e.g. heat bridges

Goods & Services

treatment of metal parts to prevent corrosion Chemical products for treatments aimed at improving corrosion resistance Speed changers, namely, speed change gears being parts of machines

Abstract

In one aspect, a medium voltage power converter includes a plurality of slices each having: a transformer including a plurality of primary windings to couple to a utility source of input power and a plurality of secondary windings; and a plurality of power cubes coupled to the plurality of secondary windings, each of the plurality of power cubes comprising a low frequency front end stage, a DC link, and a high frequency silicon carbide (SiC) inverter stage to couple to a high frequency load or to a high speed machine.

IPC Classes  ?

• H02M 5/458 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only
• H02P 27/08 - Arrangements or methods for the control of AC motors characterised by the kind of supply voltage using variable-frequency supply voltage, e.g. inverter or converter supply voltage using DC to AC converters or inverters with pulse width modulation
• H01F 27/28 - CoilsWindingsConductive connections

Abstract

In one aspect, a medium voltage power converter includes a cabinet having: a power cube bay to house a plurality of power cubes, each of the plurality of power cubes adapted within a corresponding enclosure and comprising a low frequency front end stage, a DC link and a high frequency back end stage, the plurality of power cubes to couple to a high speed machine; and a plurality of first barriers adapted to isolate and direct a first flow of cooling air through one of the plurality of power cubes; and a transformer bay having at least one transformer to couple between a utility connection and the plurality of power cubes, the transformer bay including a plurality of cooling fans to cool the at least one transformer.

IPC Classes  ?

• H05K 7/20 - Modifications to facilitate cooling, ventilating, or heating
• H02B 1/56 - CoolingVentilation
• H02P 27/08 - Arrangements or methods for the control of AC motors characterised by the kind of supply voltage using variable-frequency supply voltage, e.g. inverter or converter supply voltage using DC to AC converters or inverters with pulse width modulation
• H02M 5/458 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only
• H02M 7/00 - Conversion of AC power input into DC power outputConversion of DC power input into AC power output

Abstract

In one aspect, a medium voltage power converter includes a cabinet having: a power cube bay to house a plurality of power cubes, each of the plurality of power cubes adapted within a corresponding enclosure and comprising a low frequency front end stage, a DC link and a high frequency back end stage, the plurality of power cubes to couple to a high speed machine; and a plurality of first barriers adapted to isolate and direct a first flow of cooling air through one of the plurality of power cubes; and a transformer bay having at least one transformer to couple between a utility connection and the plurality of power cubes, the transformer bay including a plurality of cooling fans to cool the at least one transformer.

IPC Classes  ?

• H05K 7/20 - Modifications to facilitate cooling, ventilating, or heating
• H02B 1/56 - CoolingVentilation
• H02P 27/08 - Arrangements or methods for the control of AC motors characterised by the kind of supply voltage using variable-frequency supply voltage, e.g. inverter or converter supply voltage using DC to AC converters or inverters with pulse width modulation
• H02M 5/458 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only
• H02M 7/00 - Conversion of AC power input into DC power outputConversion of DC power input into AC power output

Goods & Services

Game services provided on-line from a computer network.

Goods & Services

Game services provided on-line from a computer network.

Abstract

A method and a device are used to generate a control command. A resolution base value and a resolution-tick corresponding function are created. A first operation frequency value, a minimal tick value and a resolution value are received to calculate a resolution ratio and a second operation frequency. A conversional tick value is calculated. If or not the conversional tick value is greater than or equal to the minimal tick value is determined. If the conversion tick value is smaller than the minimal tick value, the minimal tick value, the conversional tick value and the second operation frequency are used to calculate a conversional operation frequency. A conversional resolution ratio is calculated according to the first operation frequency and the conversional operation frequency, and also a modified tick value is calculated. The control command is output according to the modified tick value, the first operation frequency and the conversion operation frequency.

IPC Classes  ?

• G05B 11/01 - Automatic controllers electric
• G05B 19/29 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by positioning or contouring control systems, e.g. to control position from one programmed point to another or to control movement along a programmed continuous path using an absolute digital measuring device for point-to-point control
• G05B 19/33 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by positioning or contouring control systems, e.g. to control position from one programmed point to another or to control movement along a programmed continuous path using an analogue measuring device

Goods & Services

Game services provided on-line from a computer network

Goods & Services

Electronic game services provided on-line from a computer network

Abstract

A control command resolution adjustment method and a command generation device are disclosed in present invention. The control command resolution adjustment method is used to adjust a control command form the command generation device. A calculation frequency value via the command generation device is analyzed. The control command is received and a transform frequency value via the control command is analyzed. A first resolution value is calculated from the calculation frequency value and the transform frequency value. The first resolution value is distinguished greater than or equal to a minimum resolution value. When the first resolution value less than the minimum resolution value, an added calculation frequency value is calculated from the calculation frequency value and a frequency added value. A second resolution value is calculated from the added calculation frequency value and the transform frequency value. When the second resolution value greater than or equal to the minimum resolution value, the control command via the second resolution value is outputted.

IPC Classes  ?

• G05B 13/02 - Adaptive control systems, i.e. systems automatically adjusting themselves to have a performance which is optimum according to some preassigned criterion electric

Abstract

This disclosure includes anti-reverse rotation apparatuses, rotors for use therein, and related methods. Some apparatuses include a stator defining an interior volume and one or more arcuate contact surfaces within the interior volume, and a rotor rotatably coupled to the stator and at least partially disposed within the interior volume, the rotor having a hub, two or more shoes, each pivotally coupled to the hub and extending between a first end and a second end that is farther from the hub than is the first end, wherein each of the shoes is rotatable relative to the hub between: (a) a first position in which the second end of the shoe contacts at least one of the arcuate contact surface(s) of the stator; and (b) a second position in which the second end of the shoe does not contact the arcuate contact surface(s) of the stator.

IPC Classes  ?

• F16D 51/26 - Brakes with outwardly-movable braking members co-operating with the inner surface of a drum or the like shaped as brake-shoes pivoted on a fixed or nearly-fixed axis with two brake-shoes both extending in the same direction from their pivots
• F16D 51/60 - Self-tightening brakes with pivoted brake-shoes with wedging action of a brake-shoe, e.g. the shoe entering as a wedge between the brake-drum and a stationary part
• F16D 65/09 - Pivots or supporting members therefor
• F01D 21/00 - Shutting-down of machines or engines, e.g. in emergencyRegulating, controlling, or safety means not otherwise provided for
• F04D 29/22 - Rotors specially for centrifugal pumps
• F16D 127/10 - Self-amplifying or de-amplifying mechanisms having wedging elements
• F16D 125/58 - Mechanical mechanisms transmitting linear movement

Abstract

A patrol-type preventive inspection system is provided for an inspection personnel to perform a patrol-type inspections upon a plurality of electromechanical devices located along a patrol path. In the patrol-type preventive inspection system, a portable inspection-device kit and a portable communication device are carried by the inspection personnel to a to-be-inspected position of a to-be-inspected electromechanical device out of the electromechanical devices along the patrol path, so as to perform a patrol-type inspection upon the to-be-inspected electromechanical device for obtaining at least one inspection data. When the inspection data complies with at least one preventive inspection standard, the portable communication device is provided for the inspection user to perform an interactive operation to generate a real rapid-screening result, further to generate a preliminary treatment suggestion, and to re-plan the patrol path.

IPC Classes  ?

• G05B 23/00 - Testing or monitoring of control systems or parts thereof
• G05B 23/02 - Electric testing or monitoring
• G07C 1/20 - Checking timed patrols, e.g. of watchman
• G06Q 10/00 - AdministrationManagement

Goods & Services

(1) Electric motors for machines; motors used in industrial applications; electric starter motors, other than for land vehicles; motors for boats; pumps are parts of machines, engines and motors; rotary pumps; starters for motors and engines; variable frequency drives for motors and engines; medium voltage motors; low voltage motors; gear motors; variable frequency drives for motors, other than for land vehicles; washing machines; magnetic starters for motors and engines; direct online starters for motors and engines (2) Magnetic contactors, electric; circuit breakers; relays, electric; electronic overload relays; thermal overload relays; DC/AC inverters; inverters for power supply; electronic controllers used to reduce power consumption; electric control panels; programmable logical controllers, namely an industrial digital computer designed for the control of manufacturing processes for industrial automation; power amplifiers; signal amplifiers; electronic signal conditioning modules for use in the field of Industrial machines; electric timers; electric power converters; power distribution and power control switchboards; power adapters for computers; electronic servo motor controllers; touch screens; touch computer monitors

Abstract

A system includes a control module, a velocity-detecting module and a state-analyzing module. The control module generates a control command to control the servo drive system, and bases on the control command to define angular-acceleration standard ranges with respect to detection times. The velocity-detecting module detects output angular-velocity values of the servo motor with respect to detection times upon when the servo motor is driven. The state-analyzing module includes a processing unit and an abnormal-state judging unit. The processing unit stores the output angular-velocity values, and bases on the output angular-velocity values to calculate output angular-acceleration values with respect to the detection times. The abnormal-state judging unit determines whether or not each of the output angular-acceleration values with respect to each of the corresponding detection times is within the respective angular-acceleration standard range and thereby to generate corresponding comparison results.

IPC Classes  ?

• H02P 29/10 - Arrangements for regulating or controlling electric motors, appropriate for both AC and DC motors for preventing overspeed or under speed
• G05B 23/02 - Electric testing or monitoring

Abstract

A motor with self power generation includes a motor body, at least one magnetic element, a shield case, an induction element, a transfer circuit board and a working module. The motor body includes a shaft member. The at least one magnetic element, located at the shaft member, is to generate a dynamic electromagnetic induction space while the shaft member rotates. The shield case, located close to the shaft member, is to shield the shaft member. The induction element, fixed at the shield case, has a portion located inside the dynamic electromagnetic induction space to generate an induction power while the shaft member rotates. The transfer circuit board has a transfer circuit electrically coupled with the induction element to receive the induction power to further generate a working power. The working module, electrically coupled with the transfer circuit, is to receive the working power to execute a default work.

IPC Classes  ?

• H02K 53/00 - Alleged dynamo-electric perpetua mobilia
• H02K 47/20 - Motor/generators
• H02K 11/00 - Structural association of dynamo-electric machines with electric components or with devices for shielding, monitoring or protection
• H02K 9/06 - Arrangements for cooling or ventilating by ambient air flowing through the machine having means for generating a flow of cooling medium with fans or impellers driven by the machine shaft
• H02K 7/18 - Structural association of electric generators with mechanical driving motors, e.g.with turbines

Abstract

A rotor structure of synchronous reluctance motor which includes at least one rotor sheet is provided in the present invention. The rotor sheet has a center hole and includes a plurality of reluctance units surrounded the center hole. The reluctance units have an inner through-hole pair and an outer through-hole pair. In an inner through hole of the inner through-hole pair and an outer through hole of the outer through-hole pair, an inner tangent extension and an outer tangent extension are extended along a tangent extension direction. Two oblique extensions are extended from the inner tangent extension and the outer tangent extension along a turning direction which is oblique to the tangent extension direction respectively. An oblique included angle of the outer through hole is smaller than an oblique included angle of the inner through hole.

IPC Classes  ?

• H02K 1/22 - Rotating parts of the magnetic circuit
• H02K 1/24 - Rotor cores with salient poles
• H02K 19/02 - Synchronous motors

Abstract

In one embodiment, a power cell module includes: a high frequency line converter (HFLC) to receive a phase of input power from a utility source, the HFLC including a first silicon carbide (SiC) stage and a second SiC stage; a transformer having a primary coil coupled to the HFLC and a secondary coil coupled to a high frequency motor converter (HFMC); the HFMC to output a phase of output power to a load, the HFMC including a third SiC stage and a fourth SiC stage; and a two-phase cooling system having conduits that are adapted to provide a flow of cooling media through the HFLC, the transformer and the HFMC.

IPC Classes  ?

• H05K 7/20 - Modifications to facilitate cooling, ventilating, or heating
• H02M 5/458 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only
• H02M 5/22 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases without intermediate conversion into DC by static converters using discharge tubes with control electrode or semiconductor devices with control electrode
• H01L 23/473 - Arrangements for cooling, heating, ventilating or temperature compensation involving the transfer of heat by flowing fluids by flowing liquids
• H02P 27/06 - Arrangements or methods for the control of AC motors characterised by the kind of supply voltage using variable-frequency supply voltage, e.g. inverter or converter supply voltage using DC to AC converters or inverters
• H02M 7/49 - Combination of the output voltage waveforms of a plurality of converters

Abstract

A method includes steps of: preparing first and second plates, each first plate having surrounding apertures, each aperture including a first accommodation portion and an outer necking portion, each second plate having surrounding accommodation portions; stacking the first plates by aligning necking portions to form band gaps extending linearly and parallel to each other; stacking two second plates to two opposing terminal portions of the stacked first plates; penetrating metal bars into the aligned first and second accommodation portions by exposing both ends of each metal bar; beetling the necking portions at each band gap so as to locate firmly the corresponding metal bar; positioning a first mold and a second mold to clamp the stacked plate structure; injecting metal slurries into the first and second molds and then solidifying the metal slurries to form two end rings; and, removing the first and second molds to complete a rotor structure.

IPC Classes  ?

• H02K 15/02 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines of stator or rotor bodies
• H02K 15/12 - Impregnating, moulding insulation, heating or drying of windings, stators, rotors or machines
• B23P 15/00 - Making specific metal objects by operations not covered by a single other subclass or a group in this subclass
• H02K 15/00 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines
• B23P 11/00 - Connecting or disconnecting metal parts or objects by metal-working techniques, not otherwise provided for

Abstract

In one embodiment, a system includes a plurality of slices each having a transformer including a primary winding to couple to an input power source and a plurality of secondary windings each to couple to one of a plurality of power cells of the slice. Each of the power cells of a first slice may have an output that is phase rotated with respect to a correspondingly positioned power cell of a second slice.

IPC Classes  ?

• H02M 7/48 - Conversion of DC power input into AC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode
• H02M 5/458 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only

Abstract

A system for managing real-time work information of a motor fitting provides a sensor set at the motor fitting to transmit the real-time work information to a processing module. A processing unit of the processing module sends type information and a real-time work parameter according to the real-time work information. When a detection unit determines the real-time work parameter is fallen outside a normal work parameter according to a lookup table stored in a database and the type information, the detection unit generates an abnormal-notification signal for transmission. When an application procedure of the application-processing unit is triggered, the application-processing unit activates a play unit to play the normal work parameter, and further the activated play unit plays notification information upon receiving the abnormal-notification signal.

IPC Classes  ?

• G06F 19/00 - Digital computing or data processing equipment or methods, specially adapted for specific applications (specially adapted for specific functions G06F 17/00;data processing systems or methods specially adapted for administrative, commercial, financial, managerial, supervisory or forecasting purposes G06Q;healthcare informatics G16H)
• G06F 19/26 - for data visualisation, e.g. graphics generation, display of maps or networks or other visual representations
• G05B 19/406 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by monitoring or safety
• G05B 19/19 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by positioning or contouring control systems, e.g. to control position from one programmed point to another or to control movement along a programmed continuous path
• H02P 29/04 - Arrangements for regulating or controlling electric motors, appropriate for both AC and DC motors by means of a separate brake
• H02P 6/08 - Arrangements for controlling the speed or torque of a single motor
• H02P 6/182 - Circuit arrangements for detecting position without separate position detecting elements using back-emf in windings

Abstract

A side winding motor stator includes a plurality of stator structures, a plurality of winding structures and a plurality of winding rolls. The stator structures are assembled to form a stator module. Each of the stator structures includes a stator tooth and an insulated frame. The stator tooth is configured into the insulated frame. The insulated frame has a gap. The winding structures, each of which has a plurality of lateral slots, are engaged through the gap. The winding rolls are engaged in the lateral slots.

IPC Classes  ?

• H02K 3/28 - Layout of windings or of connections between windings
• H02K 3/18 - Windings for salient poles
• H02K 3/52 - Fastening salient pole windings or connections thereto

Abstract

In one embodiment, a power cell chamber for a drive system includes moveable and fixed portions. The moveable portion includes a rectifier stage to rectify an input signal received from a secondary winding of a transformer to provide a rectified signal and an inverter stage having a plurality of switching devices to receive a DC signal and output an AC signal. This moveable portion can be slidably adapted within a cabinet of the drive system. In turn, the fixed portion includes a DC link having at least one capacitor to receive the rectified signal and provide the DC signal to the inverter stage.

IPC Classes  ?

• H05K 5/00 - Casings, cabinets or drawers for electric apparatus
• H05K 7/14 - Mounting supporting structure in casing or on frame or rack
• H02M 7/00 - Conversion of AC power input into DC power outputConversion of DC power input into AC power output
• H02M 7/49 - Combination of the output voltage waveforms of a plurality of converters

Abstract

A system for mounting a control panel (2) to the enclosure (3) of an inverter (4) comprises at least one seat (5) for positioning the panel (2) and formed on the outside surface (6) of the enclosure (3), a locking device (7) by which the panel (2) is locked to the seat (5) and an engagement device (8) by which the panel (2) can be engaged with the seat (5) in at least two predetermined relative positions alternative to each other.

IPC Classes  ?

• H05K 7/14 - Mounting supporting structure in casing or on frame or rack
• H05K 5/02 - Casings, cabinets or drawers for electric apparatus Details
• H05K 5/00 - Casings, cabinets or drawers for electric apparatus

Abstract

An electric motor which comprises a casing (2), a driving shaft (3), at least partly housed in the casing (2), which extends outside the casing (2) at least at a first end (4) of the shaft (3) and at least one accessory unit (6) connected to the first end (4) of the driving shaft (3); the electric motor also comprises disassemblable connecting means (10) for connecting the accessory unit (6) to the first end (4) of the shaft (3) to allow removal and/or fitting of the accessory unit (6), passing from at least a first to a second configuration.

IPC Classes  ?

• H02K 7/00 - Arrangements for handling mechanical energy structurally associated with dynamo-electric machines, e.g. structural association with mechanical driving motors or auxiliary dynamo-electric machines
• H02K 7/102 - Structural association with clutches, brakes, gears, pulleys or mechanical starters with friction brakes
• H02K 11/00 - Structural association of dynamo-electric machines with electric components or with devices for shielding, monitoring or protection
• H02K 9/06 - Arrangements for cooling or ventilating by ambient air flowing through the machine having means for generating a flow of cooling medium with fans or impellers driven by the machine shaft

Goods & Services

Variable frequency drives for motors, other than for land vehicles

Abstract

In an embodiment, a drive system includes a transformer enclosed in an enclosure including a heat exchanger to cool a fluid medium. In addition, the system includes a plurality of power cubes each including a rectifier, a DC-link, and an inverter. Each power cube may include a plurality of cold plates each coupled to a corresponding switching device of the inverter, an inlet port in communication with a first one of the plurality of cold plates and an outlet port in communication with a last one of the plurality of cold plates. In turn, a manifold assembly is to couple at least the power cubes to enable two phase cooling of the power cubes and the transformer via one or more heat exchangers.

IPC Classes  ?

• H05K 7/20 - Modifications to facilitate cooling, ventilating, or heating
• H01F 27/18 - Liquid cooling by evaporating liquids
• H02M 7/00 - Conversion of AC power input into DC power outputConversion of DC power input into AC power output

Abstract

In an embodiment, a power converter includes: a plurality of power amplifier units, each having: a plurality of slice each with a power conversion module including an AC/DC/AC converter; a mains controller to control the plurality of slices; and a feedback conditioning system coupled to the mains controller; a plurality of input contactors and a plurality of output contactors via which each of the plurality of power amplifier units is to couple between a transformer and a load; and a master controller coupled to the plurality of power amplifier units.

IPC Classes  ?

• H02M 5/458 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a triode or transistor type requiring continuous application of a control signal using semiconductor devices only
• H02M 7/49 - Combination of the output voltage waveforms of a plurality of converters
• H02M 5/453 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a triode or transistor type requiring continuous application of a control signal
• H02M 7/00 - Conversion of AC power input into DC power outputConversion of DC power input into AC power output

Abstract

In an embodiment, a power converter includes: a plurality of power amplifier units, each having: a plurality of slice each with a power conversion module including an AC/DC/AC converter; a mains controller to control the plurality of slices; and a feedback conditioning system coupled to the mains controller; a plurality of input contactors and a plurality of output contactors via which each of the plurality of power amplifier units is to couple between a transformer and a load; and a master controller coupled to the plurality of power amplifier units.

IPC Classes  ?

• H02M 5/451 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a thyratron or thyristor type requiring extinguishing means using semiconductor devices only with automatic control of output voltage or frequency
• H02M 5/45 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters using discharge tubes or semiconductor devices to convert the intermediate DC into AC using devices of a thyratron or thyristor type requiring extinguishing means using semiconductor devices only

Abstract

Cooling assemblies, such as those configured to cool electric machines (e.g., electric motors and generators) and components of electric machines (e.g., rotors and stators).

IPC Classes  ?

• H02K 9/00 - Arrangements for cooling or ventilating
• H02K 9/19 - Arrangements for cooling or ventilating for machines with closed casing and closed-circuit cooling using a liquid cooling medium, e.g. oil
• H02K 3/24 - Windings characterised by the conductor shape, form or construction, e.g. with bar conductors with channels or ducts for cooling medium between the conductors
• H02K 9/22 - Arrangements for cooling or ventilating by solid heat conducting material embedded in, or arranged in contact with, the stator or rotor, e.g. heat bridges
• H02K 1/24 - Rotor cores with salient poles

Abstract

In an example embodiment, a cooling system is a pumpless passive system, and includes a cold plate configured to receive a flow of liquid coolant and to output a flow of vapor phase coolant, where the cold plate includes at least one heat pipe adapted therein to provide for transfer of the liquid coolant to the vapor phase coolant, a first connection member coupled to the at least one heat pipe, a first conduit coupled to the first connection member, the first conduit extending vertically to enable at least the vapor phase coolant to travel through the first conduit, and a heat exchanger located above and coupled to the first conduit, where the heat exchanger is to transfer the vapor phase coolant to the liquid coolant.

IPC Classes  ?

• H02J 1/00 - Circuit arrangements for dc mains or dc distribution networks
• H05K 7/20 - Modifications to facilitate cooling, ventilating, or heating
• F28D 15/02 - Heat-exchange apparatus with the intermediate heat-transfer medium in closed tubes passing into or through the conduit walls in which the medium condenses and evaporates, e.g. heat-pipes

Abstract

Cooling apparatuses and methods comprising cooling apparatuses, such as those configured to be coupled to and/or cool electric machines (e.g., motors, generators, and the like).

IPC Classes  ?

• H02K 9/19 - Arrangements for cooling or ventilating for machines with closed casing and closed-circuit cooling using a liquid cooling medium, e.g. oil
• H02K 9/16 - Arrangements for cooling or ventilating wherein gaseous cooling medium circulates between the machine casing and a surrounding mantle wherein the cooling medium circulates through ducts or tubes within the casing
• H02K 5/20 - Casings or enclosures characterised by the shape, form or construction thereof with channels or ducts for flow of cooling medium

Abstract

Cooling assemblies and methods, including, for example, at least one bar (e.g., electrically insulated and/or thermally conductive bar(s)), members (e.g., i-beams, rectangular members, and the like), stator laminations, rotor laminations, and/or combinations thereof, such as those configured to cool electric machines (e.g., electric motors and generators).

IPC Classes  ?

• H02K 9/22 - Arrangements for cooling or ventilating by solid heat conducting material embedded in, or arranged in contact with, the stator or rotor, e.g. heat bridges
• H02K 15/00 - Processes or apparatus specially adapted for manufacturing, assembling, maintaining or repairing of dynamo-electric machines
• H02K 1/20 - Stationary parts of the magnetic circuit with channels or ducts for flow of cooling medium
• H02K 1/32 - Rotating parts of the magnetic circuit with channels or ducts for flow of cooling medium

Goods & Services

Electric motors, gear reducers, gear motors, speed variators, motor variators, drive mechanisms.

Goods & Services

Dog shoes; dog collars; clothing for dogs; dog bellybands (clothing); folding briefcases; shoulder bags; Gladstone bags; Japanese wicker trunks (kori); briefcases; suitcases; carry-on bags; trunks; handbags; Boston bags; schoolchildren's backpacks; rucksacks; charm bags (ommamori-ire); card cases; shopping bags (including wheeled shopping bags); purses; key cases; money pouches; wallets; luggage label holders; business card cases; telescopic umbrellas; Japanese paper umbrellas (karakasa); Japanese oiled-paper umbrellas (janome-gasa); rainproof parasols; beach umbrellas; parasols; umbrellas; umbrella covers; umbrella handles; metal parts of umbrellas; frames for umbrellas; bags for umbrellas; leather; leather straps; rawhides; raw skins; tanned leather; fur. Evening dresses; children's wear; jackets; jogging pants; sweat pants; suits; skirts; ski jackets; ski pants; trousers; smocks; formalwear; overcoats; topcoats; mantles; raincoats; cardigans; sweaters; vests and waistcoats; open-necked shirts; cuffs; collars for clothing; sport shirts; blouses; polo shirts; shirts for suits; night gowns; negligees; Japanese sleeping robes (nemaki); pajamas; bath robes; undershirts; corsets for underclothing; combinations for clothing; chemises; drawers and underpants; slips; panties, shorts and briefs; brassieres; petticoats; swimwear; swimming caps; camisoles; T-shirts; Japanese traditional clothing; sash bands for kimono (obi); bustle holder bands for obi (obiage); bustles for obi-knots (obiage-shin); waist strings for kimonos (koshihimo); undershirts for kimonos (koshimaki); undershirts for kimonos (juban); tightening-up strings for kimonos (datejime); wrap belts for kimonos (datemaki); full-length kimonos (nagagi); short overcoat for kimono (haori); string fasteners for haori (hacri-himo); pleated skirts for formal kimonos (hakama); detachable neckpieces for kimonos (haneri); sleep masks; aprons for clothing; collar protectors for wear; socks and stockings; puttees and gaiters; fur stoles; shawls; scarves; Japanese style socks (tajbi); Japanese style socks covers (tabi covers); gloves and mittens for clothing; bandanas; thermal supporters for clothing; mufflers; ear muffs for clothing; nightcaps; headgear for wear; garters; sock suspenders; suspenders; waistbands; belts for clothing; rain boots; leather shoes; sandal for shoes; sneaker; Japanese split-toed work footwear (jikatabi); boots; women's shoes; winter boots; infants' shoes and boots; inner soles for shoes and boots; heelpieces for shoes and boots; insoles for shoes and boots; welts for shoes and boots; rubber soles for jikatabi; footwear uppers; tips for footwear; shoe soles for repair; Japanese style, wooden clogs (geta); high rain clogs (ashida); low wooden clogs (koma-geta); sandal-clogs; low wooden clogs (hiyori-geta); metal fittings for Japanese style wooden clogs; wooden bodies for Japanese style clogs; toe straps for Japanese style wooden clogs; Japanese style sandals (zori); Japanese toe-strap sandals (asaura-zori); Japanese style sandals of leather; slippers; Japanese style sandals of felt; Japanese footwear of rice straw (waraji); slipper soles; uppers for Japanese style sandals; soles for Japanese style sandals; uppers of woven rattan for Japanese style sandals; toe straps for Japanese style sandals; special footwear for sports; golf shoes; soccer shoes; ski boots; snowboarding shoes; gymnastic shoes; climbing boots; bowling shoes; boxing shoes; hockey shoes; baseball shoes; rugby shoes; footwear for track and field athletics; horse-riding boots.

Goods & Services

Motors and engines, transmission components and generic parts of machines; Electrical engines. Instruments, indicators for measuring, investigating and monitoring; Frequency converters.

Abstract

A cryostat cartridge is disclosed. The cryostat cartridge may include a cryostat having a cryogen inlet, a cryogen outlet, and a superconductor material inside the cryostat configured to be cooled by a cryogen entering the cryostat through the cryogen inlet and exiting the cryostat through the cryogen outlet. The cryogen inlet is configured to be detachable from a cryogen source. The cryostat cartridge may be inserted into an activation module for activating the superconductor material and may also be inserted into a superconductor device.

IPC Classes  ?

• H01F 27/08 - CoolingVentilating

Abstract

[Problem] The present invention relates to a new pump unit which is capable of preventing an impact and vibration which are generated when a pump for discharging (filling) a capsule liquid is in operation at a high speed while manufacturing a capsule by coating the capsule liquid with an outer coating part, expanding a length of time of capsule liquid discharge and an actual fillable area, and controlling a discharge pressure which may increase during a high-speed rotation. [Solution] According to the pump unit of the present invention, an end of a plunger pin is extended to protrude out of a pump chamber, and receives driving by a shifter at the protruding portion for a reciprocating movement in the pump chamber. The shifter comprises a rotating pendulum lever, and the plunger pin reciprocates in the pump chamber due to a reciprocating rotation of the pendulum lever.

IPC Classes  ?

• A61J 3/07 - Devices or methods specially adapted for bringing pharmaceutical products into particular physical or administering forms into the form of capsules or similar small containers for oral use
• A61K 9/48 - Preparations in capsules, e.g. of gelatin, of chocolate
• A61K 47/42 - ProteinsPolypeptidesDegradation products thereofDerivatives thereof, e.g. albumin, gelatin or zein
• B67C 3/00 - Bottling liquids or semiliquidsFilling jars or cans with liquids or semiliquids using bottling or like apparatusFilling casks or barrels with liquids or semiliquids

Abstract

A control system may be provided for a controlled system such as a drive or inverter system. To provide for control in such system, a master controller may be present to receive, via a second communication protocol from a cabinet controller coupled to the master controller, status information of a controlled device, generate control information based at least in part on the status information, and transmit the control information to the cabinet controller via the second communication protocol. In turn, the cabinet controller can generate and communicate a control packet to the controlled device via a first communication protocol. This packet can be interleaved within another message communicated from the cabinet controller to the device.

IPC Classes  ?

• G06F 13/00 - Interconnection of, or transfer of information or other signals between, memories, input/output devices or central processing units
• G06F 13/364 - Handling requests for interconnection or transfer for access to common bus or bus system with centralised access control using independent requests or grants, e.g. using separated request and grant lines

Abstract

In an embodiment, a medium voltage drive system includes a transformer, multiple power cubes each coupled to the transformer, and a manifold assembly. Each power cube includes cold plates each coupled to a corresponding switching device of the cube, an inlet port in communication with a first one of the cold plates and an outlet port in communication with a last one of the cold plates. The manifold assembly can support an inlet conduit and an outlet conduit and further support first and second connection members to enable blind mating of each of the first connection members to the inlet port of one of the power cubes and each of the second connection members to the outlet port of one of the power cubes to enable two phase cooling of the plurality of power cubes.

IPC Classes  ?

• H05K 7/20 - Modifications to facilitate cooling, ventilating, or heating
• H05K 7/14 - Mounting supporting structure in casing or on frame or rack
• H02M 7/00 - Conversion of AC power input into DC power outputConversion of DC power input into AC power output

Goods & Services

Electric motors for machines

Abstract

In one embodiment, a power cell chamber for a drive system includes moveable and fixed portions. The moveable portion includes a rectifier stage to rectify an input signal received from a secondary winding of a transformer to provide a rectified signal and an inverter stage having a plurality of switching devices to receive a DC signal and output an AC signal. This moveable portion can be slidably adapted within a cabinet of the drive system. In turn, the fixed portion includes a DC link having at least one capacitor to receive the rectified signal and provide the DC signal to the inverter stage.

IPC Classes  ?

• H05K 7/14 - Mounting supporting structure in casing or on frame or rack
• H02M 7/00 - Conversion of AC power input into DC power outputConversion of DC power input into AC power output
• H02M 7/49 - Combination of the output voltage waveforms of a plurality of converters

Goods & Services

Motors, generators, pumps, compressors, wind-powered generators, solar-powered generators, washing machines, vacuum cleaners, starters for motors, servo-drives, magnetic motor starters, direct on-line starters and direct on-line magnetic motor starters, engines and motors for the generation of electricity. Motor drives, magnetic switches, magnetic contactor, circuit breakers, inverters [electricity], programmable controller, human machine interface, transformers, electronic and overload relays, electrical switch timers, switchgear [electric], voltage regulators. Air conditioners, dehumidifiers, ventilators, household air cleaners, air-circulators, water coolers, electric toasters, microwave ovens [cooking apparatus], electromagnetic ovens, electric coffee pots, refrigerators.

Abstract

Rotors with trapped-field magnet (TFM) bulks, machines with TFM rotors, and methods of activating and/or using machines with TFM rotors.

IPC Classes  ?

• H02K 1/27 - Rotor cores with permanent magnets
• H02K 55/02 - Dynamo-electric machines having windings operating at cryogenic temperatures of the synchronous type
• H01F 6/00 - Superconducting magnetsSuperconducting coils

Goods & Services

Engines and motors for the generation of electricity; Windmills for generating electricity; Wind-powered generators; solar-powered generators; water-powered generators; Wind turbines; blades of wind power generator; mill towers and masts. Photovoltaic cells and modules; solar panels for production of electricity; Photovoltaic inverters; Solar cells; electrical power converters; wind- solar hybrid modules; power distribution and power control switchboards.

Abstract

Disclosed is a novel manufacturing method, which is a manufacturing procedure wherein a capsule is formed by combining starch, λ-carrageenan, metallic salt, a plasticiser, and water as the structural component composition for the raw materials for the outer-skin part of the capsule, and which has enhanced the drying ability of conventional rotary-die type soft capsule manufacturing methods, enabling the water content of a capsule outer-skin sheet to be freely adjusted, and which also has improved the previously problematic post-formation hardness-stability of the capsule. In the disclosed soft capsule manufacturing method a capsule is formed by combining starch, λ-carrageenan, metallic salt, a plasticiser, and water as the structural component composition for the raw materials for the outer-skin part of the capsule. In addition to being a novel method wherein trisodium citrate is mixed as the metallic salt, the method is characterised by the introduction to conventional rotary-die type automatic soft capsule manufacturing methods of a drying procedure for the capsule outer-skin sheet using medium wavelength infra-red radiation, thus enhancing drying ability and enabling the water content of the capsule outer-skin sheet to be freely adjusted.

IPC Classes  ?

• A61K 9/48 - Preparations in capsules, e.g. of gelatin, of chocolate
• A61K 47/04 - Non-metalsCompounds thereof
• A61K 47/12 - Carboxylic acidsSalts or anhydrides thereof
• A61K 47/36 - PolysaccharidesDerivatives thereof, e.g. gums, starch, alginate, dextrin, hyaluronic acid, chitosan, inulin, agar or pectin

Abstract

In one embodiment, a transformer is provided for coupling between a utility connection and a plurality of power cells of a drive system. The transformer may be of a horizontal arrangement and include a housing and a core configured within the housing and having multiple columns each adapted along a horizontal axis. Each column corresponds to a phase, and each phase includes a coil having primary winding and multiple secondary windings concentrically adapted about the column horizontal axis to provide an air gap between adjacent ones of the primary and secondary windings. In addition, the transformer may include a baffler adapted about the core and configured within the housing to prevent air flow at a periphery of the coils and to direct air flow through the air gaps of the coils.

IPC Classes  ?

• H05K 5/00 - Casings, cabinets or drawers for electric apparatus
• H01F 27/08 - CoolingVentilating
• H01F 27/02 - Casings

Abstract

In one embodiment, the present invention includes a medium voltage drive system having multiple power cells each to couple between a transformer and a load. A first subset of the power cells are configured to provide power to the load and to perform partial regeneration from the load, and a second subset of the power cells are configured to provide power to the load but not perform partial regeneration. A controller may be included in the system to simultaneously control a DC bus voltage of at least one of the first subset of the power cells, correct a power factor of the system, and provide harmonic current compensation for the system.

IPC Classes  ?

• H02M 1/12 - Arrangements for reducing harmonics from AC input or output

Abstract

An apparatus for manufacturing a soft capsule containing a filling coated with a shell portion formed of a shell-sheet, having a sheet molding section forming a shell-sheet having an almost uniform thickness from a molten shell material, a capsule molding section feeding shell-sheets between a pair of die rolls and joining the shell sheets, and a filling supply section supplying a filling to the shell-sheets in time for joining the shell-sheets, in which the sheet molding section has a dryer equipped with a medium wavelength infrared heater; the shell-sheet is irradiated with a medium wavelength infrared ray from the heater to thereby obtain an almost uniform thickness, an appropriate viscosity, and moisture content; and the sheet of this state is fed to the capsule molding section.

IPC Classes  ?

• B65B 47/00 - Apparatus or devices for forming pockets or receptacles in or from sheets, blanks, or webs, comprising essentially a die into which the material is pressed or a folding die through which the material is moved

Abstract

The disclosed headrest support device is formed with a synthetic thermoplastic resin material as a base, in an effort to reduce overall weight. The headrest support device is provided to the top of the seatback of a seat for a vehicle, holds a headrest that supports the head of a seat occupant, and is such that the height in the vertical direction of the headrest can be adjusted. The headrest support device is caused to comprise two stay guides (1, 1) into which two headrest stays (81, 81) provided to the headrest (8) couple, and which fulfill the role of holding said two headrest stays (81, 81) at a predetermined position; strip-shaped staying-pressing sections (15, 15) that are a portion of each of the tubular sections (11, 11) forming the stay guides (1, 1) and that are formed at a portion in the axial direction of the tubular sections (11, 11); and holding clips (2, 2) that are provided to the place on the tubular sections containing the staying-pressing sections (15, 15) and that move so as to press said staying-pressing sections (15, 15) towards the inner surface.

IPC Classes  ?

• B60N 2/48 - Head-rests
• A47C 7/38 - Supports for the head or the back for the head, e.g. detachable

Abstract

In one embodiment, a power cell chamber for a drive system includes moveable and fixed portions. The moveable portion includes a rectifier stage to rectify an input signal received from a secondary winding of a transformer to provide a rectified signal and an inverter stage having a plurality of switching devices to receive a DC signal and output an AC signal. This moveable portion can be slidably adapted within a cabinet of the drive system. In turn, the fixed portion includes a DC link having at least one capacitor to receive the rectified signal and provide the DC signal to the inverter stage.

IPC Classes  ?

• H02H 3/00 - Emergency protective circuit arrangements for automatic disconnection directly responsive to an undesired change from normal electric working condition, with or without subsequent reconnection

Abstract

In one embodiment, the present invention includes a turbine to generate mechanical energy from kinetic energy, a generator coupled to the turbine to receive the mechanical energy and to output multiple isolated supply powers, and multiple power stages each coupled to the generator. Each of the power stages may receive at least one of the isolated supply powers.

IPC Classes  ?

• H02K 6/00 -

Abstract

In one embodiment, the present invention includes a system having multiple modular transformers each including a primary winding coupled to an input power source and phase-shifted secondary windings each coupled to a power cell. The system further includes different phase output lines coupled to a load. These lines may include first, second and third phase output lines.

IPC Classes  ?

• H02M 5/42 - Conversion of AC power input into AC power output, e.g. for change of voltage, for change of frequency, for change of number of phases with intermediate conversion into DC by static converters
• H02J 1/12 - Parallel operation of dc generators with converters, e.g. with mercury-arc rectifier

Abstract

In one embodiment, the present invention includes a turbine to generate mechanical energy from kinetic energy, a generator coupled to the turbine to receive the mechanical energy and to output multiple isolated supply powers, and multiple power stages each coupled to the generator. Each of the power stages may receive at least one of the isolated supply powers.

IPC Classes  ?

• F03D 7/00 - Controlling wind motors
• F03D 11/02 - Transmission of power, e.g. using hollow exhausting blades

Abstract

In one embodiment, a power cell chamber for a drive system includes moveable and fixed portions. The moveable portion includes a rectifier stage to rectify an input signal received from a secondary winding of a transformer to provide a rectified signal and an inverter stage having a plurality of switching devices to receive a DC signal and output an AC signal. This moveable portion can be slidably adapted within a cabinet of the drive system. In turn, the fixed portion includes a DC link having at least one capacitor to receive the rectified signal and provide the DC signal to the inverter stage.

IPC Classes  ?

• H02J 7/00 - Circuit arrangements for charging or depolarising batteries or for supplying loads from batteries
• H02M 7/48 - Conversion of DC power input into AC power output without possibility of reversal by static converters using discharge tubes with control electrode or semiconductor devices with control electrode
• H01M 10/46 - Accumulators structurally combined with charging apparatus

Abstract

In one embodiment, a power cell chamber for a drive system includes moveable and fixed portions. The moveable portion includes a rectifier stage to rectify an input signal received from a secondary winding of a transformer to provide a rectified signal and an inverter stage having a plurality of switching devices to receive a DC signal and output an AC signal. This moveable portion can be slidably adapted within a cabinet of the drive system. In turn, the fixed portion includes a DC link having at least one capacitor to receive the rectified signal and provide the DC signal to the inverter stage.

IPC Classes  ?

• H01H 33/32 - Power arrangements internal to the switch for operating the driving mechanism using fluid actuator pneumatic
• H01R 13/62 - Means for facilitating engagement or disengagement of coupling parts or for holding them in engagement

Abstract

In one embodiment, the present invention includes a turbine to generate mechanical energy from kinetic energy, a generator coupled to the turbine to receive the mechanical energy and to output multiple isolated supply powers, and multiple power stages each coupled to the generator. Each of the power stages may receive at least one of the isolated supply powers.

IPC Classes  ?

• H02K 6/00 -

Abstract

In one embodiment, a medium voltage drive system includes at least one transformer and multiple power cell chambers each coupled to a transformer. The power cell chambers each may include a rectifier, a DC-link, and an inverter. Each power cell chamber can be separated into fixed and moveable portions, where the moveable portion includes the rectifier and the inverter and the fixed portion includes the DC-link. A power service bus can couple the fixed and moveable portions of each power cell chamber and couple in series groups of the plurality of power cell chambers.

IPC Classes  ?

• H02H 9/00 - Emergency protective circuit arrangements for limiting excess current or voltage without disconnection

Goods & Services

Generator for land vehicles;  fuel filters for vehicles. Fuel economizers. Motors for land vehicles; electric motors for land vehicles; driver for land vehicles; engine for land vehicles;  brake hardware for vehicles;  electric starting components of the engine for vehicles use; coupling of automobiles; torque converters for land vehicles; electric vehicles; electric bicycles; motor cars; motorcycles; gasoline, diesel, hybrid vehicles; transmissions for land vehicles; power transmissions for land vehicles; energy accumulating and discharging motors for vehicles (for charging or discharging energy); all the aforesaid goods included in class 12.

Goods & Services

[ Automobiles and structural parts thereof, ] [ electric cars, electric bicycles, ] [ motor cars for transport on land, motorcycles, ] motors and engines for land vehicles, electric motors for land vehicles, electric drive transmissions for land vehicles, transmissions for automobiles, power transmissions for land vehicles [ and replacement parts thereof, ] energy accumulating and discharging motors for land vehicles [, brake hardware for vehicles, coupling of automobiles, torque converters for land vehicles ]

Abstract

A transformer module includes a main primary winding coupled to a first input power source to receive a medium voltage signal, multiple main secondary windings each to couple to a power cell of a drive system, and an auxiliary primary winding coupled to a second input power source to receive a low voltage signal. The auxiliary primary winding can be spatially separated from the main windings to increase leakage inductance. The auxiliary primary winding can be active during a pre-charge operation to pre-charge the power cells.

IPC Classes  ?

• H02J 1/10 - Parallel operation of dc sources

Abstract

Stator for use in an electrical machine. A non-magnetic support frame section and a non-magnetic axial coil support are used to provide an air gap stator configuration. The present stators provide an air gap winding configuration that facilitates the fixing of stator coils in the air gap. The stator coils are located near the surface of the magnetic back iron and are separated from adjacent coils by non-magnetic structure.

IPC Classes  ?

• H02K 3/48 - Fastening of windings on the stator or rotor structure in slots
• H02K 1/06 - Details of the magnetic circuit characterised by the shape, form or construction

Abstract

Stator for use in an electrical machine. A non-magnetic support frame section and a non-magnetic coil support are used to provide an air gap stator configuration. The present stators provide an air gap winding configuration that facilitates the fixing of stator coils in the air gap, spaced apart from the magnetic back iron.

IPC Classes  ?

• H02K 1/00 - Details of the magnetic circuit

Abstract

Disclosed are soft capsules having been widely used in 旜drugs”, 旜foods for specific health uses”, 旜so-called health foods” and foods which have soft and excellent mastication properties and a high meltability in the oral cavity, impart a mild and full-bodied taste to a gelatin film coating, show an excellent ability to regulate the stickiness of the capsule film coating to thereby prevent sticking of the capsules to each other or to a container, and further inhibit an increase in the moisture content of the gelatin film coating even under highly humid conditions and so on. Soft capsules to be masticated characterized in that a gelatin film coating for the soft capsules to be masticated is formed by blending a powdery fat with gelatin, a plasticizer and water.

IPC Classes  ?

• A61K 9/48 - Preparations in capsules, e.g. of gelatin, of chocolate
• A23L 1/00 - Foods or foodstuffs; Their preparation or treatment (preservation thereof in general A23L 3/00)
• A23L 1/30 - containing additives (A23L 1/308 takes precedence);;
• A61K 47/14 - Esters of carboxylic acids, e.g. fatty acid monoglycerides, medium-chain triglycerides, parabens or PEG fatty acid esters
• A61K 47/42 - ProteinsPolypeptidesDegradation products thereofDerivatives thereof, e.g. albumin, gelatin or zein

Abstract

The garment has a garment body and expanded bags which are disposed at any bag placement positions on the garment body. The expanded bag is created by encapsulating at least foam resin particles as a filler inside of a stretchable bag.

IPC Classes  ?

• A41D 13/00 - Professional, industrial or sporting protective garments, e.g. surgeons' gowns or garments protecting against blows or punches
• A41D 1/00 - Garments
• A41D 13/06 - Knee or foot
• A41D 13/08 - Arm or hand
• A42B 1/08 - Soft capsHoods with protection against blows

Abstract

In one embodiment, the present invention includes a medium voltage drive system having multiple power cells each to couple between a transformer and a load. A first subset of the power cells are configured to provide power to the load and to perform partial regeneration from the load, and a second subset of the power cells are configured to provide power to the load but not perform partial regeneration. A controller may be included in the system to simultaneously control a DC bus voltage of at least one of the first subset of the power cells, correct a power factor of the system, and provide harmonic current compensation for the system.

IPC Classes  ?

• H02M 1/12 - Arrangements for reducing harmonics from AC input or output

Abstract

In one embodiment, the present invention includes a turbine to generate mechanical energy from kinetic energy, a generator coupled to the turbine to receive the mechanical energy and to output multiple isolated supply powers, and multiple power stages each coupled to the generator. Each of the power stages may receive at least one of the isolated supply powers.

IPC Classes  ?

• F30D 9/00 -
