A fence post mount device comprising: a base having at least one cavity; a first universal collet having a plurality of collet legs attached to each other through at least one of a plurality of separation notches, wherein a distal end of the first universal collet is inserted into the cavity from a proximal end of the base; a first cap nut inserted into the first universal collet; a post inserted into the cavity of the base; a full thread nut threaded into the first cap nut from a distal end of the base through an opening, wherein each of the plurality of separation notches are broken when the full thread nut is tightened into the first cap nut and each of the collet legs of the first universal collet deforms an inner wall of the post such that the post is securely locked within the cavity of the base.
A method of assembling a deck board by using a step clip fastening device is disclosed. The method comprising the steps of fastening the step clip fastening device onto a joist by using a plurality of fastening tools; sliding a first end of the deck board into an inner cavity of a step clip attached at a first end of the step clip fastening device; and snapping a second end of the deck board into an inner cavity of a corresponding step clip facing the step clip attached at the first end of the step clip fastening device to form a mating relationship between the deck board and the step clip fastening device.
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
E04F 13/24 - Hidden fastening means on the rear of the covering or lining elements
E04F 15/02 - Flooring or floor layers composed of a number of similar elements
Disclosed is a fence system. The fence system, comprising: a first post; a second post, wherein each of the first post and the second post comprises a first set of ribs and a second set of ribs; a lower rail, wherein a first end of the lower rail is adapted to terminate at a face of the first set of ribs of the first post and a second end of the lower rail is adapted to terminate at a face of the first set of ribs of the second post; and an upper rail, wherein the lower rail and the upper rail are positioned to receive one or more infill boards, such that the one or more infill boards are adapted to terminate at a face of the second set of ribs of the first post and at a face of the second set of ribs of the second post.
A step clip fastening device, the step clip fastening device comprising: an elongated base strip having a first end and a second end, wherein a female locking part is attached to the first end and a male locking part is attached to the second end; a plurality of step clip sets extending substantially perpendicularly upwards from the base strip, wherein each of the step clip set comprising at least two step clips arranged in a back-to-back configuration, wherein a step clip is attached at each of the first end and the second end of the base strip; an anchor protruded at a center of each of the step clip; and one or more tabs extending substantially perpendicularly downwards from the base strip between two corresponding step clips facing each other.
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
E04F 13/24 - Hidden fastening means on the rear of the covering or lining elements
E04F 15/02 - Flooring or floor layers composed of a number of similar elements
A system includes a first mid-rail slit positioned at a first position. A second mid-rail slit is positioned at a second position directly across from the first mid-rail slit. A first and second stile are positioned between the first and second mid-rail slit. The first and second stile are inserted and positioned in a perpendicular direction to a bottom panel to be aligned in a vertical direction between the first and second mid-rail slit. The first and second stile provide separation for a plurality of decorative screen panels. The plurality of decorative screen panels are positioned in contact with the first and second stile.
Kits for assembling rackable gates are provided. The kits comprise a pair of gate uprights, each gate upright comprising a tubular elongate member and a bracket. The tubular elongate member comprises apertures configured to accept a fence panel rail therethrough and into an elongate channel situated on an interior surface therein and configured to securely receive an end of the fence panel rail such that lateral and torsional movement of said fence panel rail is restricted. The bracket comprises a pair of bracket arms attached to an exterior surface of the tubular elongate member, each situated directly opposite the other with an aperture situated therebetween and configured to accommodate a fastener for fastening a fence panel rail thereto. Also provided are methods for assembling gates from such kits and gates assembled from such kits and by such methods.
Devices for extending the height of a barrier are provided. The devices comprise an elongate member having a downward-facing rail channel comprising a plurality of opposed longitudinal projections extending inwardly into the rail channel, a decorative accent feature mounted on the top surface of the elongate member and extending upwardly therefrom, and a top rail mounted onto a top surface of the decorative accent feature. The devices are configured for downward installation onto the top rail of a barrier panel, whereby a first pair of the opposed longitudinal projections rest on any upwardly facing surface of the top rail, while at least one further pair of the opposed longitudinal projections contacts the opposing side-facing surfaces of the top rail. Also provided are systems comprising these devices, as well as methods for installing these systems onto the top rail of a barrier panel.
A system includes a post configured at an initial position. The system also includes a plurality of ribs within an inner channel of the post. A front set of ribs are positioned at a front portion of the inner channel. A back set of ribs are positioned at a back portion of the inner channel. The back set of ribs are configured to receive a different set of boards than the front set of ribs. In the system, the set of boards are positioned within the back set of ribs within the inner channel of the post.
E04H 17/16 - Fences constructed of rigid elements, e.g. with additional wire fillings or with posts using prefabricated panel-like elements, e.g. wired frames
A system includes a top rail configured at an initial position. The system also includes one or more plugs positioned underneath the top rail. The one or more plugs and top rail are positioned within a same connected device. The one or more plugs include spring clips to enable the top rail and one or more plugs to be connected to a top portion of a fence. The system also includes a mid-rail positioned at the top portion of the fence, wherein the mid-rail is configured to receive the one or more plugs.
E04H 17/16 - Fences constructed of rigid elements, e.g. with additional wire fillings or with posts using prefabricated panel-like elements, e.g. wired frames
A system includes a top rail configured at a first position. The system also includes a bottom rail configured at a second position below the top rail. The system also includes a first set of clips positioned on the top rail. The system also includes a second set of clips positioned on the bottom rail. The system further includes a plurality of screws inserted in an area within the front portion of the first set of clips and the second set of clips.
A system includes a board at an initial position. The system also includes a first connecting apparatus positioned at one end of the boards. The first connecting apparatus includes a front end configured to be positioned within an opening of the board and a bottom end configured to be positioned within a fence structure. The system also includes a second connecting apparatus positioned at another end of the board. The second connecting apparatus includes a front end configured to be positioned within another opening of the board and a bottom end configured to be positioned within the fence structure. The system also includes a plurality of corner posts configured to receive the first connecting apparatus and the second connecting apparatus.
E04H 17/16 - Fences constructed of rigid elements, e.g. with additional wire fillings or with posts using prefabricated panel-like elements, e.g. wired frames
E04H 17/14 - Fences constructed of rigid elements, e.g. with additional wire fillings or with posts
06 - Common metals and ores; objects made of metal
19 - Non-metallic building materials
Goods & Services
Metal structural components for exterior and interior screen systems, namely, aluminum framing posts and rails, powder coated screens, and pre-fabricated screen doors; Kits for making aluminum screen doors, window screens, and screen railing infills comprised of metal structural components, namely, aluminum posts, aluminum rails, and powder coated screens Kits comprising non-metal structural components for making exterior and interior screen systems, namely, screen railing infill kits
A system includes a top rail configured at a first position. The system also includes a bottom rail configured at a second position below the top rail. The system also includes a first set of clips positioned on the top rail. The system also includes a second set of clips positioned on the bottom rail. The system further includes a plurality of screws inserted in an area within the front portion of the first set of clips and the second set of clips.
A system includes a first mid-rail slit positioned at a first position. A second mid-rail slit is positioned at a second position directly across from the first mid-rail slit. A first and second stile are positioned between the first and second mid-rail slit. The first and second stile are inserted and positioned in a perpendicular direction to a bottom panel to be aligned in a vertical direction between the first and second mid-rail slit. The first and second stile provide separation for a plurality of decorative screen panels. The plurality of decorative screen panels are positioned in contact with the first and second stile.
E04H 17/14 - Fences constructed of rigid elements, e.g. with additional wire fillings or with posts
E04H 17/16 - Fences constructed of rigid elements, e.g. with additional wire fillings or with posts using prefabricated panel-like elements, e.g. wired frames
Kits for assembling rackable gates are provided. The kits comprise a pair of gate uprights, each gate upright comprising a tubular elongate member and a bracket. The tubular elongate member comprises apertures configured to accept a fence panel rail therethrough and into an elongate channel situated on an interior surface therein and configured to securely receive an end of the fence panel rail such that lateral and torsional movement of said fence panel rail is restricted. The bracket comprises a pair of bracket arms attached to an exterior surface of the tubular elongate member, each situated directly opposite the other with an aperture situated therebetween and configured to accommodate a fastener for fastening a fence panel rail thereto. Also provided are methods for assembling gates from such kits and gates assembled from such kits and by such methods.
Devices for extending the height of a barrier are provided. The devices comprise an elongate member having a downward-facing rail channel comprising a plurality of opposed longitudinal projections extending inwardly into the rail channel, a decorative accent feature mounted on the top surface of the elongate member and extending upwardly therefrom, and a top rail mounted onto a top surface of the decorative accent feature. The devices are configured for downward installation onto the top rail of a barrier panel, whereby a first pair of the opposed longitudinal projections rest on any upwardly facing surface of the top rail, while at least one further pair of the opposed longitudinal projections contacts the opposing side-facing surfaces of the top rail. Also provided are systems comprising these devices, as well as methods for installing these systems onto the top rail of a barrier panel.
A system includes a board at an initial position. The system also includes a first connecting apparatus positioned at one end of the boards. The first connecting apparatus includes a front end configured to be positioned within an opening of the board and a bottom end configured to be positioned within a fence structure. The system also includes a second connecting apparatus positioned at another end of the board. The second connecting apparatus includes a front end configured to be positioned within another opening of the board and a bottom end configured to be positioned within the fence structure. The system also includes a plurality of comer posts configured to receive the first connecting apparatus and the second connecting apparatus.
A system includes a post configured at an initial position. The system also includes a plurality of ribs within an inner channel of the post. A front set of ribs are positioned at a front portion of the inner channel. A back set of ribs are positioned at a back portion of the inner channel. The back set of ribs are configured to receive a different set of boards than the front set of ribs. In the system, the set of boards are positioned within the back set of ribs within the inner channel of the post.
A system includes a top rail configured at an initial position. The system also includes one or more plugs positioned underneath the top rail. The one or more plugs and top rail are positioned within a same connected device. The one or more plugs include spring clips to enable the top rail and one or more plugs to be connected to a top portion of a fence. The system also includes a mid-rail positioned at the top portion of the fence, wherein the mid-rail is configured to receive the one or more plugs.
E04H 17/14 - Fences constructed of rigid elements, e.g. with additional wire fillings or with posts
E04H 17/16 - Fences constructed of rigid elements, e.g. with additional wire fillings or with posts using prefabricated panel-like elements, e.g. wired frames
F16B 5/06 - Joining sheets or plates to one another or to strips or bars parallel to them by means of clamps or clips
F16B 5/07 - Joining sheets or plates to one another or to strips or bars parallel to them by means of multiple interengaging protrusions on the surfaces, e.g. hooks, coils
A system includes one or more decorative screen panels configured at an initial position. The system also includes a locking and spacing apparatus positioned on an exterior portion of the one or more decorative screen panels. The spacer is positioned to receive a locking mechanism. The locking mechanism is positioned on the locking and spacing apparatus over the one or more decorative screen panels. A first portion of the locking mechanism is positioned within the spacer. A second portion of the locking mechanism is positioned under the locking and spacing apparatus and configured to move in a perpendicular direction. The movement in the perpendicular direction secures the locking mechanism within the locking and spacing apparatus.
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
A system includes one or more decorative screen panels configured at an initial position. The system also includes a locking and spacing apparatus positioned on an exterior portion of the one or more decorative screen panels. The spacer is positioned to receive a locking mechanism. The locking mechanism is positioned on the locking and spacing apparatus over the one or more decorative screen panels. A first portion of the locking mechanism is positioned within the spacer. A second portion of the locking mechanism is positioned under the locking and spacing apparatus and configured to move in a perpendicular direction. The movement in the perpendicular direction secures the locking mechanism within the locking and spacing apparatus.
A system includes an initial position identified to build one or more connected structures. The system also includes one or more corner brackets attached to a plurality of frame members at the initial position. The system also includes a plurality of mid-beams and center braces positioned in between each of the frame members and each of the corner brackets to enable decorative screen panels to be placed between each of the frame members and corner brackets. The decorative screen panels are positioned over the mid-beams and center beams and in between the corner brackets and frame members. The system also includes a plurality of corner posts each inserted into one of the corner brackets. The corner posts, combined with the corner brackets form a T-shaped frame around the decorative screen panels.
A deck tile assembly is disclosed. The deck tile assembly comprises a frame having at least four sides. The deck tile assembly further comprises a plurality of bars for providing a support structure to the frame. The deck tile assembly further comprises at least two parallel sleepers permanently attached between two opposite sides of the frame and mounted on the plurality of bars. The deck tile assembly further comprises at least two step clip fastening devices, wherein each of the step clip fastening device is mounted on one of the at least two parallel sleepers. The deck tile assembly further comprises at least two supporting members for attaching the frame with the ground surface.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A system includes an initial position identified to build one or more connected structures. The system also includes one or more corner brackets attached to a plurality of frame members at the initial position. The system also includes a plurality of mid-beams and center braces positioned in between each of the frame members and each of the corner brackets to enable decorative screen panels to be placed between each of the frame members and corner brackets. The decorative screen panels are positioned over the mid-beams and center beams and in between the corner brackets and frame members. The system also includes a plurality of corner posts each inserted into one of the corner brackets. The corner posts, combined with the corner brackets form a T-shaped frame around the decorative screen panels.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
E04H 17/10 - Wire fencing, e.g. made of wire mesh characterised by the way of connecting wire to the postsDroppers
E04H 17/12 - Wire fencing, e.g. made of wire mesh characterised by the way of connecting wire to the postsDroppers the wire being placed in slots, grooves, or the like
E04H 17/24 - Connections for attaching additional wire to frames, posts or railings
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
E04H 17/10 - Wire fencing, e.g. made of wire mesh characterised by the way of connecting wire to the postsDroppers
E04H 17/12 - Wire fencing, e.g. made of wire mesh characterised by the way of connecting wire to the postsDroppers the wire being placed in slots, grooves, or the like
E04H 17/24 - Connections for attaching additional wire to frames, posts or railings
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
E04H 17/10 - Wire fencing, e.g. made of wire mesh characterised by the way of connecting wire to the postsDroppers
E04H 17/12 - Wire fencing, e.g. made of wire mesh characterised by the way of connecting wire to the postsDroppers the wire being placed in slots, grooves, or the like
E04H 17/24 - Connections for attaching additional wire to frames, posts or railings
A cable railing assembly having a plurality of posts, an expandable cable guide assembly, and a tensioning apparatus, and a method of assembling the cable railing assembly. The expandable cable guide assembly includes a pair of cable braces with a cable extending in a serpentine fashion between the cable braces. The tensioning apparatus includes a tensioner base, a tensioner body, a compression spring positioned between the tensioner base and the tensioner body, a movable carriage slidably mounted adjacent the tensioner body and comprising a cable clamp for gripping the cable, and a threaded adjuster secured to the body and operative for moving the movable carriage along the body.
E04H 17/10 - Wire fencing, e.g. made of wire mesh characterised by the way of connecting wire to the postsDroppers
E04H 17/12 - Wire fencing, e.g. made of wire mesh characterised by the way of connecting wire to the postsDroppers the wire being placed in slots, grooves, or the like
E04H 17/24 - Connections for attaching additional wire to frames, posts or railings
A deck tile assembly is disclosed. The deck tile assembly comprises a frame having at least four sides. The deck tile assembly further comprises a plurality of bars for providing a support structure to the frame. The deck tile assembly further comprises at least two parallel sleepers permanently attached between two opposite sides of the frame and mounted on the plurality of bars. The deck tile assembly further comprises at least two step clip fastening devices, wherein each of the step clip fastening device is mounted on one of the at least two parallel sleepers. The deck tile assembly further comprises at least two supporting members for attaching the frame with the ground surface.
A fence post mount device comprising: a base having at least one cavity; a first universal collet having a plurality of collet legs attached to each other through at least one of a plurality of separation notches, wherein a distal end of the first universal collet is inserted into the cavity from a proximal end of the base; a first cap nut inserted into the first universal collet; a post inserted into the cavity of the base; a full thread nut threaded into the first cap nut from a distal end of the base through an opening, wherein each of the plurality of separation notches are broken when the full thread nut is tightened into the first cap nut and each of the collet legs of the first universal collet deforms an inner wall of the post such that the post is securely locked within the cavity of the base.
06 - Common metals and ores; objects made of metal
19 - Non-metallic building materials
Goods & Services
(1) Metal structural components for exterior or interior construction of screen rooms.
(2) Non-metal structural components for exterior or interior construction of screen rooms.
A method of assembling a deck board by using a step clip fastening device is disclosed. The method comprising the steps of fastening the step clip fastening device onto a joist by using a plurality of fastening tools; sliding a first end of the deck board into an inner cavity of a step clip attached at a first end of the step clip fastening device; and snapping a second end of the deck board into an inner cavity of a corresponding step clip facing the step clip attached at the first end of the step clip fastening device to form a mating relationship between the deck board and the step clip fastening device.
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
E04F 13/24 - Hidden fastening means on the rear of the covering or lining elements
E04F 15/02 - Flooring or floor layers composed of a number of similar elements
A magnetic safety gate latch assembly and method of operation. The assembly includes: a pool latch tube, a user-actuated coupled to the top end of the pool latch tube; a rotatable shaft within the pool latch tube, an upper end of the shaft rigidly coupled to the lid, and a lower end of the shaft including a shaped base. The assembly further includes a magnet housing that at least partially encloses the shaped base and includes an aperture to cooperatively engage with the shaped base. The assembly further includes a bottom cover coupled to the lower end of the pool latch tube and enclosing the magnet housing, the bottom cover including an aperture facing a latch pin housing, the aperture positioned to expose a magnet. The assembly further includes a ferromagnetic latch pin and housing, and a magnetic latch pin guide slidably enclosing the latch pin.
A step clip fastening device, the step clip fastening device comprising: an elongated base strip having a first end and a second end, wherein a female locking part is attached to the first end and a male locking part is attached to the second end; a plurality of step clip sets extending substantially perpendicularly upwards from the base strip, wherein each of the step clip set comprising at least two step clips arranged in a back-to-back configuration, wherein a step clip is attached at each of the first end and the second end of the base strip; an anchor protruded at a center of each of the step clip; and one or more tabs extending substantially perpendicularly downwards from the base strip between two corresponding step clips facing each other.
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
E04F 13/24 - Hidden fastening means on the rear of the covering or lining elements
E04F 15/02 - Flooring or floor layers composed of a number of similar elements
A fence post mount device comprising: a base having at least one cavity; a first universal collet having a plurality of collet legs attached to each other through at least one of a plurality of separation notches, wherein a distal end of the first universal collet is inserted into the cavity from a proximal end of the base; a first cap nut inserted into the first universal collet; a post inserted into the cavity of the base; a full thread nut threaded into the first cap nut from a distal end of the base through an opening, wherein each of the plurality of separation notches are broken when the full thread nut is tightened into the first cap nut and each of the collet legs of the first universal collet deforms an inner wall of the post such that the post is securely locked within the cavity of the base.
A racked fence gate assembly comprises an upright having a longitudinal opening and a lateral opening. The assembly also includes an insert received within the longitudinal opening and coupled to the upright. The insert also includes a support portion extending from a rear wall. The assembly further includes a rail having trimmable areas at proximal and distal ends that is at least partially received within a cavity of the insert at a racking angle, the rail including a channel configured to at least partly receive the support portion therein.
06 - Common metals and ores; objects made of metal
Goods & Services
(1) Metal brackets and cable railings, namely, bars for metal railings, railings of metal for balconies, metal railings for fencing, decking, handrails and banisters, metal brackets for use in the construction and assembly of decking.
The present disclosure relates generally to a column cover comprising a first portion comprising a first side panel having a first edge and a second edge, a second side panel having a first edge and a second edge, a front panel extending between the second edge of the first side panel and the second edge of the second side panel, and an outer surface having at least one textured contour that replicates a natural building material. The cover further comprises a second portion comprising a first side panel having a first edge and a second edge, wherein the first side panel of the second portion is substantially coplanar with the first side panel of the first portion, wherein the first edge of the first side panel of the first portion is spaced apart from the first edge of the first side panel of the second portion.
E04C 3/36 - ColumnsPillarsStruts of materials not covered by groups or ColumnsPillarsStruts of a combination of two or more materials
E04F 13/073 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of specially adapted, structured or shaped covering or lining elements for particular building parts, e.g. corners or columns
74.
COLUMN COVERS AND METHODS OF MANUFACTURE AND INSTALLATION
The present disclosure relates generally to a column cover comprising a first portion comprising a first side panel having a first edge and a second edge, a second side panel having a first edge and a second edge, a front panel extending between the second edge of the first side panel and the second edge of the second side panel, and an outer surface having at least one textured contour that replicates a natural building material. The cover further comprises a second portion comprising a first side panel having a first edge and a second edge, wherein the first side panel of the second portion is substantially coplanar with the first side panel of the first portion, wherein the first edge of the first side panel of the first portion is spaced apart from the first edge of the first side panel of the second portion.
E04F 13/073 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of specially adapted, structured or shaped covering or lining elements for particular building parts, e.g. corners or columns
E04F 13/18 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements of organic plastics with or without reinforcements or filling materials
E04F 17/02 - Vertical ductsChannels, e.g. for drainage for carrying away waste gases, e.g. flue gasesBuilding elements specially designed therefor, e.g. shaped bricks or sets thereof
A method of assembling a deck board by using a step clip fastening device is disclosed. The method comprising the steps of fastening the step clip fastening device onto a joist by using a plurality of fastening tools; sliding a first end of the deck board into an inner cavity of a step clip attached at a first end of the step clip fastening device; and snapping a second end of the deck board into an inner cavity of a corresponding step clip facing the step clip attached at the first end of the step clip fastening device to form a mating relationship between the deck board and the step clip fastening device.
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
E04F 15/02 - Flooring or floor layers composed of a number of similar elements
E04F 13/24 - Hidden fastening means on the rear of the covering or lining elements
A deck tile assembly is disclosed. The deck tile assembly comprises a frame having at least four sides. The deck tile assembly further comprises a plurality of bars for providing a support structure to the frame. The deck tile assembly further comprises at least two parallel sleepers permanently attached between two opposite sides of the frame and mounted on the plurality of bars. The deck tile assembly further comprises at least two step clip fastening devices, wherein each of the step clip fastening device is mounted on one of the at least two parallel sleepers. The deck tile assembly further comprises at least two supporting members for attaching the frame with the ground surface.
06 - Common metals and ores; objects made of metal
19 - Non-metallic building materials
35 - Advertising and business services
37 - Construction and mining; installation and repair services
Goods & Services
(1) Metal fencing, railings, decking, and hardware and accessories thereof; metal screens, panels, and lattices and hardware and accessories.
(2) Non-metal fencing, railings, decking, and hardware and accessories thereof; non-metal screens, panels, and lattices and hardware and accessories; non-metal columns, arbors, and trellises. (1) Online retail store services featuring fencing; railings, decking and hardware and accessories thereof; screens, panels; lattices and hardware and accessories; columns, arbors, and trellises.
(2) Customer support services being technical support services, namely, troubleshooting in the nature of the repair of fencing.
06 - Common metals and ores; objects made of metal
19 - Non-metallic building materials
35 - Advertising and business services
37 - Construction and mining; installation and repair services
Goods & Services
(1) Metal fencing, railings, decking, and hardware and accessories thereof; metal screens, panels, and lattices and hardware and accessories
(2) Non-metal fencing, railings, decking, and hardware and accessories thereof; non-metal screens, panels, and lattices and hardware and accessories; non-metal columns, arbors, and trellises (1) Online retail store services featuring fencing; railings, decking and hardware and accessories thereof; screens, panels; lattices and hardware and accessories; columns, arbors, and trellises
(2) Customer support services being technical support services, namely, troubleshooting in the nature of the repair of fencing
80.
System and method for vertical and horizontal in-fill installation
Disclosed is a fence system. The fence system, comprising: a first post; a second post, wherein each of the first post and the second post comprises a first set of ribs and a second set of ribs; a lower rail, wherein a first end of the lower rail is adapted to terminate at a face of the first set of ribs of the first post and a second end of the lower rail is adapted to terminate at a face of the first set of ribs of the second post; and an upper rail, wherein the lower rail and the upper rail are positioned to receive one or more infill boards, such that the one or more infill boards are adapted to terminate at a face of the second set of ribs of the first post and at a face of the second set of ribs of the second post.
Disclosed is a fence system. The fence system, comprising: a first post; a second post, wherein each of the first post and the second post comprises a first set of ribs and a second set of ribs; a lower rail, wherein a first end of the lower rail is adapted to terminate at a face of the first set of ribs of the first post and a second end of the lower rail is adapted to terminate at a face of the first set of ribs of the second post; and an upper rail, wherein the lower rail and the upper rail are positioned to receive one or more infill boards, such that the one or more infill boards are adapted to terminate at a face of the second set of ribs of the first post and at a face of the second set of ribs of the second post.
A racked fence gate assembly comprises an upright having a longitudinal opening and a lateral opening. The assembly also includesan insert received within the longitudinal opening and coupled to the upright. The insert also includes a support portion extending from a rear wall. The assembly further includes a rail having trimmable areas at proximal and distal ends that is at least partially received within a cavity of the insert at a racking angle, the rail including a channel configured to at least partly receive the support portion therein.
06 - Common metals and ores; objects made of metal
19 - Non-metallic building materials
20 - Furniture and decorative products
35 - Advertising and business services
37 - Construction and mining; installation and repair services
Goods & Services
Metal fencing, railings, and decking and accessories, namely, fence post tops, fence post finials, cable rails with installation components, namely, fence posts tops, fence post finials, cable rails; metal structures in the nature of decorative deck, patio and garden privacy screen panels; metal fence panels, and lattices; metal hardware, namely, karabiners of metal, hinges, latches, drop rods, stops, posts and rail inserts, brackets, surface mounts, clips, gate wheels, cross braces, joiners, end caps, joint rings, spacer blocks, posts, and balusters, and post mounting kits, namely, fence posts and fence infills Non-metal fencing, railings, decking, and accessories, namely, fence post tops, fence post finials, and decorative accents; non-metal structures in the nature of decorative deck, patio and garden privacy screen panels Non-metal hardware, namely, hinges, latches, drop rods, stops, posts and rail inserts, brackets, surface mounts, clips, gate wheels, cross braces, joiners, end caps, joint rings, spacer blocks, posts, and balusters, and post mounting kits, namely, fence posts and fence infills Online retail store services featuring fencing, railings, decking and hardware and accessories, screens, panels, lattices and hardware and accessories, columns, arbors, and trellises Customer support services being technical support services, namely, troubleshooting in the nature of the repair of fencing
06 - Common metals and ores; objects made of metal
19 - Non-metallic building materials
20 - Furniture and decorative products
35 - Advertising and business services
37 - Construction and mining; installation and repair services
Goods & Services
Metal fencing, railings, and decking and accessories, namely, fence post tops, fence post finials, cable rails with installation components, namely, fence posts tops, fence post finials, cable rails; metal structures in the nature of decorative deck, patio and garden privacy screen panels; metal fence panels, and lattices; metal hardware, namely, karabiners of metal, hinges, latches, drop rods, stops, posts and rail inserts, brackets, surface mounts, clips, gate wheels, cross braces, joiners, end caps, joint rings, spacer blocks, posts, and balusters, and post mounting kits, namely, fence posts and fence infills Non-metal fencing, railings, decking, and accessories, namely, fence post tops, fence post finials, and decorative accents; non-metal structures in the nature of decorative deck, patio and garden privacy screen panels Non-metal hardware, namely, hinges, latches, drop rods, stops, posts and rail inserts, brackets, surface mounts, clips, gate wheels, cross braces, joiners, end caps, joint rings, spacer blocks, posts, and balusters, and post mounting kits, namely, fence posts and fence infills Online retail store services featuring fencing, railings, decking and hardware and accessories, screens, panels, lattices and hardware and accessories, columns, arbors, and trellises Customer support services being technical support services, namely, troubleshooting in the nature of the repair of fencing
06 - Common metals and ores; objects made of metal
19 - Non-metallic building materials
20 - Furniture and decorative products
35 - Advertising and business services
37 - Construction and mining; installation and repair services
Goods & Services
Metal fencing, railings, and decking and accessories, namely, fence post tops, fence post finials, cable rails with installation components, namely, fence posts tops, fence post finials, cable rails; metal structures in the nature of decorative deck, patio and garden privacy screen panels; metal fence panels, and lattices; metal hardware, namely, karabiners of metal, hinges, latches, drop rods, stops, posts and rail inserts, brackets, surface mounts, clips, gate wheels, cross braces, joiners, end caps, joint rings, spacer blocks, posts, and balusters, and post mounting kits, namely, fence posts and fence infills Non-metal fencing, railings, decking, and accessories, namely, fence post tops, fence post finials, and decorative accents; non-metal structures in the nature of decorative deck, patio and garden privacy screen panels Non-metal hardware, namely, hinges, latches, drop rods, stops, posts and rail inserts, brackets, surface mounts, clips, gate wheels, cross braces, joiners, end caps, joint rings, spacer blocks, posts, and balusters, and post mounting kits, namely, fence posts and fence infills Online retail store services featuring fencing, railings, decking and hardware and accessories, screens, panels, lattices and hardware and accessories, columns, arbors, and trellises Customer support services being technical support services, namely, troubleshooting in the nature of the repair of fencing
06 - Common metals and ores; objects made of metal
19 - Non-metallic building materials
35 - Advertising and business services
37 - Construction and mining; installation and repair services
Goods & Services
(1) Metal fencing, railings, decking, and hardware and accessories thereof; metal screens, panels, and lattices and hardware and accessories;
(2) Non-metal fencing, railings, decking, and hardware and accessories thereof; non-metal screens, panels, and lattices and hardware and accessories; non metal arbors and trellises; non-metal and non-wood columns; (1) Online retail store services featuring fencing; railings, decking and hardware and accessories thereof; screens, panels; lattices and hardware and accessories; columns, arbors, and trellises;
(2) Customer support services being technical support services, namely, troubleshooting in the nature of the repair of fencing;
A step clip fastening device, the step clip fastening device comprising: an elongated base strip having a first end and a second end, wherein a female locking part is attached to the first end and a male locking part is attached to the second end; a plurality of step clip sets extending substantially perpendicularly upwards from the base strip, wherein each of the step clip set comprising at least two step clips arranged in a back-to-back configuration, wherein a step clip is attached at each of the first end and the second end of the base strip; an anchor protruded at a center of each of the step clip; and one or more tabs extending substantially perpendicularly downwards from the base strip between two corresponding step clips facing each other.
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
E04F 15/02 - Flooring or floor layers composed of a number of similar elements
E04F 13/24 - Hidden fastening means on the rear of the covering or lining elements
A fence post mount device comprising: a base having at least one cavity; a first universal collet having a plurality of collet legs attached to each other through at least one of a plurality of separation notches, wherein a distal end of the first universal collet is inserted into the cavity from a proximal end of the base; a first cap nut inserted into the first universal collet; a post inserted into the cavity of the base; a full thread nut threaded into the first cap nut from a distal end of the base through an opening, wherein each of the plurality of separation notches are broken when the full thread nut is tightened into the first cap nut and each of the collet legs of the first universal collet deforms an inner wall of the post such that the post is securely locked within the cavity of the base.
A fence post mount device comprising: a base having at least one cavity; a first universal collet having a plurality of collet legs attached to each other through at least one of a plurality of separation notches, wherein a distal end of the first universal collet is inserted into the cavity from a proximal end of the base; a first cap nut inserted into the first universal collet; a post inserted into the cavity of the base; a full thread nut threaded into the first cap nut from a distal end of the base through an opening, wherein each of the plurality of separation notches are broken when the full thread nut is tightened into the first cap nut and each of the collet legs of the first universal collet deforms an inner wall of the post such that the post is securely locked within the cavity of the base.
A method of assembling a deck board by using a step clip fastening device is disclosed. The method comprising the steps of fastening the step clip fastening device onto a joist by using a plurality of fastening tools; sliding a first end of the deck board into an inner cavity of a step clip attached at a first end of the step clip fastening device; and snapping a second end of the deck board into an inner cavity of a corresponding step clip facing the step clip attached at the first end of the step clip fastening device to form a mating relationship between the deck board and the step clip fastening device.
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
E04F 15/02 - Flooring or floor layers composed of a number of similar elements
E04F 13/24 - Hidden fastening means on the rear of the covering or lining elements
A magnetic safety gate latch assembly and method of operation. The assembly includes: a pool latch tube, a user-actuated lid coupled to the top end of the pool latch tube; a rotatable shaft within the pool latch tube, an upper end of the shaft rigidly coupled to the lid, and a lower end of the shaft including a shaped base. The assembly further includes a magnet housing that at least partially encloses the shaped base and includes an aperture to cooperatively engage with the shaped base. The assembly further includes a bottom cover coupled to the lower end of the pool latch tube and enclosing the magnet housing, the bottom cover including an aperture facing a latch pin housing, the aperture positioned to expose a magnet. The assembly further includes a ferromagnetic latch pin and housing, and a magnetic latch pin guide slidably enclosing the latch pin.
a fade protection feature of non-metal fencing, non-metal railings and decking for decks, porches, balconies, docks, gazebos, patios, ramps, and roof decks
A deck tile assembly is disclosed. The deck tile assembly comprises a frame having at least four sides. The deck tile assembly further comprises a plurality of bars for providing a support structure to the frame. The deck tile assembly further comprises at least two parallel sleepers permanently attached between two opposite sides of the frame and mounted on the plurality of bars. The deck tile assembly further comprises at least two step clip fastening devices, wherein each of the step clip fastening device is mounted on one of the at least two parallel sleepers. The deck tile assembly further comprises at least two supporting members for attaching the frame with the ground surface.
A deck tile assembly is disclosed. The deck tile assembly comprises a frame having at least four sides. The deck tile assembly further comprises a plurality of bars for providing a support structure to the frame. The deck tile assembly further comprises at least two parallel sleepers permanently attached between two opposite sides of the frame and mounted on the plurality of bars. The deck tile assembly further comprises at least two step clip fastening devices, wherein each of the step clip fastening device is mounted on one of the at least two parallel sleepers. The deck tile assembly further comprises at least two supporting members for attaching the frame with the ground surface.
A method of assembling at least two deck tile assemblies is disclosed. The method comprises placing a first deck tile assembly on a ground surface. A second deck tile assembly is placed on the ground surface adjacent to the first deck tile assembly. A plurality of grooves of the first deck tile assembly are aligned with a plurality of protrusions of the second deck tile assembly. A plurality of protrusions of the first deck tile assembly are also aligned with a plurality of grooves of the second deck tile assembly. The second deck tile assembly is snapped with the first deck tile assembly. The first deck tile assembly and the second deck tile assembly are fastened using a plurality of locking mechanisms. A plurality of skirting enclosing a periphery of the two assembled deck tile assemblies is attached to the deck tile assemblies.
