The present invention relates to a method for recycling of elements (1) comprising a mineral fibre material bonded by a binder agent. The method comprises: fragmenting the elements (1) for provision of a powder component (3); dispersing at least a portion of the powder component (3) in an aqueous solution (6); extraction of a first fraction (9) from the at least a portion of the powder component (3) in the aqueous solution (6); and extraction of a second fraction (10) from the at least a portion of the powder component (3) in the aqueous solution (6) for obtaining a cleaned powder component; wherein the wt%, by dry weight, of binder agent in the first fraction (9) is higher than the wt%, by dry weight, of binder agent in the second fraction (10).
A cross runner (30) for a grid of profiles of a suspended ceiling system (1), the cross runner (30) being provided with a connector (40) insertable into an opening (12) of another runner (10) of the grid of profiles. The cross runner (30) has central web (33) comprising two layers of material and is provided with a top bulb (31) and two flanges (32) at a bottom portion thereof. The connector (40) is arranged at a first end (34) of the cross runner (30) and comprises a first tongue (41) and at least one additional tongue (42). The first tongue (41) is resiliently displaceable in a first lateral direction (D1) of the cross runner (30) and is provided with a wing shaped locking tab (50) protruding in a opposite second lateral direction (D2) of the cross runner (30). The wing shaped locking tab (50) is configured to engage with a side edge portion (11) of the opening (12) in response to insertion of the connector (40) into the opening (12) such that the first tongue (41) is resiliently displaced in the first lateral direction (D1) in order to allow the wing shaped locking tab (50) to be passed through the opening (12). The wing shaped locking tab (50) has a trailing edge (52) comprising a straight locking section which extends perpendicular to the longitudinal axis (L) of the cross runner. The wing shaped locking tab (50) has a leading edge (51) comprising a straight engagement section which extends at an acute angle (C) to the longitudinal axis (L) of the cross runner (30). The invention also relates to a suspended ceiling system comprising such a cross runner.
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
Building materials for sound absorbing, acoustic insulation; architectural acoustic products, namely, sound absorbers and diffusers; acoustic tiles; acoustical panels for building Non-metal building materials, namely, ceiling boards, ceiling panels, ceiling tiles, non-metal fire-resistant boards and panels for construction; non-metal water resistant boards and panels for construction; non-metal suspended ceiling systems comprising panels; non-metal ceiling panels; non-metal tiles
C04B 28/00 - Compositions of mortars, concrete or artificial stone, containing inorganic binders or the reaction product of an inorganic and an organic binder, e.g. polycarboxylate cements
The present disclosure relates to a suspended ceiling system including at least one profile for supporting a ceiling tile, at least one suspension element, and at least one hanger for suspending the at least one profile.
E04B 9/18 - Means for suspending the supporting construction
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
E04B 9/20 - Means for suspending the supporting construction adjustable
7.
A METHOD FOR INSTALLATION OF AN ACOUSTICAL SYSTEM IN A ROOM
G06F 30/13 - Architectural design, e.g. computer-aided architectural design [CAAD] related to design of buildings, bridges, landscapes, production plants or roads
G06F 30/12 - Geometric CAD characterised by design entry means specially adapted for CAD, e.g. graphical user interfaces [GUI] specially adapted for CAD
G06F 119/10 - Noise analysis or noise optimisation
An acoustical tile member having a front surface intended to face a room, an opposing rear surface and four side surfaces connecting the front surface and the rear surface, the acoustical tile member comprising a first layer and a second layer, the first layer being associated with the front surface and comprises woodwool, wherein each of at least two opposing side surfaces of the four side surfaces is provided with a groove configuration for mounting of the acoustical tile member.
E04B 9/28 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like having grooves engaging with horizontal flanges of the supporting construction or accessory means connected thereto
B32B 3/30 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a particular shape of the outline of the cross-section of a continuous layerLayered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a layer with cavities or internal voids characterised by a layer formed with recesses or projections, e.g. grooved, ribbed
B32B 5/26 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by the presence of two or more layers which comprise fibres, filaments, granules, or powder, or are foamed or specifically porous one layer being a fibrous or filamentary layer another layer also being fibrous or filamentary
B32B 19/06 - Layered products essentially comprising natural mineral fibres or particles, e.g. asbestos, mica next to a fibrous or filamentary layer
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
G10K 11/168 - Plural layers of different materials, e.g. sandwiches
The present invention relates to a tile element comprising a tile and an anchor element associated with only one surface of the tile. The anchor element comprises a body supporting a wire lock. The anchor element is arranged in the tile such that the anchor element and the wire lock thereof becomes recessed in the tile and such that an access port of the wire lock becomes accessible from said surface of the tile. The anchor element is arranged in the tile by being molded, pressed or slotted into the tile. A tile system including a tile element is also provided.
A suspended ceiling system comprising a plurality of tile elements and a grid of profiles. The grid comprising profiles provided with support flanges arranged in a common horizontal plane and supporting the plurality of tile elements. The tile elements comprises at least one sound scattering tile element having a body and a surface layer. The body is made of sound absorptive material and has a front surface and an opposing rear surface. The sound absorptive material has a sound absorption coefficient of at least 0,3. The surface layer has sound reflecting properties and is arranged on the front surface of the body. The body is provided with a groove in the rear surface such that the body is foldable with the surface layer acting as a joint about an axis extending in parallel with the groove. The at least one sound scattering tile element supported by the profiles is folded.
The invention relates to a method for producing composite panel elements (1), said method comprising: - providing a binder comprising a) glass particles, b) at least one slag, and c) an activation system comprising at least one water-soluble calcium salt and at least one water-soluble alkali metal silicate or alkali metal carbonate compound, - providing a fibre component, - mixing at least components a) and b) of said binder with a said fibre component, - forming the mixture into composite panel elements, and - adding water to said fibre component or to said mixture or to said composite panel elements, wherein the component c) of said binder is either mixed with the fibre component together with components a) and b) or added together with said water to said fibre component or to said mixture or to said composite panel elements.
The present invention relates to a method for handling compressible acoustic panels (2). The method comprises: providing a plurality of compressible acoustic panels (2); providing at least two box-shaped distribution units (10) which are bringable to an assembled state in which one of a top part (6) and a bottom part (3) is inserted into the other of the top part (6) and the bottom part (3) for defining a box volume having a box height h1; for each box-shaped distribution unit (10), forming a stack (1) comprising at least two compressible acoustic panels (2), each stack (1) having an uncompressed height h2 which is greater than box height h1; arranging each stack (1) in the bottom part (3) of the associated box-shaped distribution unit (10); arranging the top part (6) of the associated box-shaped distribution unit on top of each stack (2); stacking the at least two box-shaped distribution units (10) and pressing the top part (6') of the uppermost box-shaped distribution unit (10') towards the bottom part (3'') of the lowermost box-shaped distribution unit (10'') for bringing each box-shaped distribution unit (10) to the assembled state. The present invention further relates to a system (12) for handling compressible acoustic panels (2).
B65D 85/07 - Containers, packaging elements or packages, specially adapted for particular articles or materials for compressible or flexible articles
B65D 85/62 - Containers, packaging elements or packages, specially adapted for particular articles or materials for stacks of articlesContainers, packaging elements or packages, specially adapted for particular articles or materials for special arrangements of groups of articles
B65B 63/02 - Auxiliary devices, not otherwise provided for, for operating on articles or materials to be packaged for compressing or compacting articles or materials prior to wrapping or insertion in containers or receptacles
B65B 35/50 - Stacking one article, or group of articles, upon another before packaging
The present invention relates to a method for recycling mineral fiber material, the method comprising: providing the mineral fiber material (6) obtained from recycled mineral fiber material elements (2) comprising mineral fibers bonded by means of binder material; mixing the mineral fiber material (6) and an additional binder material (12), thereby obtaining a mixture (15); compacting the mixture (15), thereby obtaining a compacted mixture (17); and subjecting the mixture (15) to E-beam radiation for cross-linking of the binder material and the additional binder material (12), thereby obtaining a cross-linked mixture (21). The present invention further relates to a system for carrying out the method.
D04H 1/558 - Non-woven fabrics formed wholly or mainly of staple fibres or like relatively short fibres from fleeces or layers composed of fibres without existing or potential cohesive properties by welding together the fibres, e.g. by partially melting or dissolving in combination with mechanical or physical treatments other than embossing
D04H 1/74 - Non-woven fabrics formed wholly or mainly of staple fibres or like relatively short fibres characterised by the method of forming fleeces or layers, e.g. reorientation of fibres the fibres being orientated, e.g. in parallel
The present disclosure relates to a grid of profiles for a suspended ceiling system, comprising a primary profile having a web, and a first and second secondary profile each having an end provided with a hook-on member, and methods of use thereof.
E04B 9/12 - Connections between non-parallel members of the supporting construction
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
The present disclosure relates to a grid of profiles with a primary profile provided with a bulb portion extending in a longitudinal direction of the primary profile, a secondary profile comprising a connector at an end of the secondary profile, and a connection clip comprising a base portion configured for mounting to the bulb portion of the primary profile and a projecting flange provided with an opening, the opening being configured for reception of the connector of the secondary profile from a first side of the projecting flange and also a connector of an opposing secondary profile from a second side of the projecting flange.
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
Packing, stopping and insulating materials; materials made
of mineral wool, wood wool, wood fibre, rock wool, glass
fibre and glass wool for insulation, sound proofing and
sound absorption; sound proofing materials; sound absorbing
materials; insulating, sound proofing and sound absorbing
materials in the form of panels, boards, wood slabs, wood
ribs and slabs with or without facing; mineral wool, wood
wool, wood fibre, rock wool, glass fibre and glass wool
fabrics and paint for insulating, sound proofing and sound
absorbing materials; coating materials for insulating, sound
proofing and sound absorbing purposes. Non-metallic building materials, including building panels,
building tiles, building slabs, ceilings, ceiling tiles,
panels and slabs, wall panels, slabs, boards and tiles,
claddings, linings and coatings for walls and ceilings in
buildings; facings for building materials; partitions not of
metal; building materials for coating walls and ceilings
(other than paint); non-metallic coating materials (other
than paints).
06 - Common metals and ores; objects made of metal
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
24 - Textiles and textile goods
27 - Floor and wall coverings
37 - Construction and mining; installation and repair services
40 - Treatment of materials; recycling, air and water treatment,
42 - Scientific, technological and industrial services, research and design
Goods & Services
Construction materials of metal; ceilings of metal,
construction panels, panels, plates and tiles of metal; wall
coverings, linings and coverings of metal for walls
(construction); metal grill systems for ceilings; suspension
systems of metal for ceilings; grills, rods, hangers,
profiles, laths, joints and clips of metal for ceilings and
walls; parts and accessories (not included in other classes)
for all the above products. Rubber, gutta-percha, gum, asbestos, mica and goods made
from these materials and not included in other classes;
plastics in extruded form for use in manufacture; packing,
stopping and insulating materials; flexible pipes not of
metal; insulating materials for heat and acoustic insulation
and sealing; insulating materials of mineral wool, glass
fibers and rock fibers; insulating materials in the nature
of bands, sheets, felts, canvas, panels, plates, strips,
molds, pipes, rolls and molded parts, for heat and acoustic
insulation and sealing; insulating fabrics; acoustic
screens; barriers for protection against sound; insulating
paints; sealing compounds; sealing materials and sealing
joint preparations; filling putty; sound-absorbing wall and
ceiling coverings; industrial insulating coating; insulating
refractory materials; acoustic coatings for acoustic
insulation; acoustic plaster for acoustic insulation;
plaster for noise absorption and acoustic enhancement;
parts, component parts and accessories for all the aforesaid
goods, not included in other classes. Construction materials, not of metal, including construction
panels, construction bricks, construction plates, ceilings,
ceiling panels, panels, slabs, plates, side wall panels,
plates and clinker stone, coatings; facings, linings and
coverings for walls and ceilings in buildings; plaster;
coatings [building materials]; building materials of natural
stone; building materials of rock fibers; acoustic wooden
panels for ceilings; ceiling panels, not of metal; spackling
compound; coatings for joints; Ceilings not of metal made
with textiles coated with synthetic materials and stretched
on a frame; surfaces and coatings for construction
materials; partitions and partition screens (not of metal),
grills, rods, hangers, profiles, laths, seals and clips, not
of metal, for ceilings and walls; screens (construction
materials, not of metal); parts, component parts and
accessories for all the aforesaid goods, not included in
other classes. Knitted or woven textiles coated with synthetic materials
for ceiling coverings and wall hangings. Wall hangings and coverings other than of textile, for
covering ceilings, and coverings for covering floors, all
having soundproofing properties. Building construction and renovation work; roofing,
maintenance, cleaning, repair, conversion and renovation of
building complexes; civil engineering works; installation of
ceilings and wall coverings with knitted or woven textiles
coated with synthetic materials; information concerning
construction and construction and insulating materials;
rental of construction and site tools, equipment and
machinery; construction; renovation and maintenance of
buildings; building insulation; cleaning of buildings
[interior]; demolition of buildings; removal of debris from
buildings and constructions. Waste treatment (transformation); recycling of waste;
technical information and advice on the treatment and
recycling of waste; recycling of debris from buildings and
constructions; treatment of construction and insulation
materials; custom assembly of materials for third parties. Architectural consultancy; advice with respect to energy
saving; technical advice with respect to climate control and
room acoustics; diagnostic services for thermal, acoustic,
sound insulation, sealing of buildings; software as a
service [SaaS] in the field of diagnostics for thermal,
acoustic, sound insulation, sealing of buildings; technical
information and advice with respect to thermal, acoustic,
sound insulation, sealing of buildings.
The present disclosure relates to a method for manufacturing of porous geopolymer product. The method comprises providing ground mineral fibre material (2) obtained from recycled mineral fibre objects, providing a mixture (4) comprising the ground mineral fibre material, activated carbon, activator, fibre component, and water, wherein the activated carbon is present in an amount of 0.1- 10% by weight of the mixture, forming the mixture (6) into a desired shape, and curing the mixture (8), thereby obtaining the geopolymer product. The present disclosure further relates to a geopolymer product, and use of the geopolymer product.
C04B 28/00 - Compositions of mortars, concrete or artificial stone, containing inorganic binders or the reaction product of an inorganic and an organic binder, e.g. polycarboxylate cements
The present invention relates to a panel unit for a suspended ceiling. The panel unit comprises: a first and second panel member, each of the first and a second panel member being provided with a respective at least one connector, each connector comprising a shaft with a first end and an opposing second end, and a head portion arranged at the first end, wherein the second end is fixed to the respective panel member such that the shaft extends from a surface of the panel member with the head portion arranged at a distance from the surface; and a connecting element for suspension of the panel unit and for angled connection of the first and second panel member to each other, the connecting element comprising a first and a second leg connected to each other in an angled relationship for forming a V- shaped structure, the connecting element being configured such that the first and second leg extend obliquely upwards in a suspended state of the panel unit; wherein each of the first and second leg is provided with a groove extending in a leg direction associated with the respective first and second leg, and wherein each groove is configured to receive a respective connector such that the head portion engages an upwardly facing surface of the leg in the suspended state of the panel unit.
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/24 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like positioned on, or held against, horizontal flanges of the supporting construction
22.
MOUNTING BRACKET CONFIGURED TO BE MOUNTED ON A CEILING FRAMING MEMBER
The mounting bracket (100) comprises a first portion (102) having a front side (108) and a back side (106) and a second portion (104) The first portion (102) comprises a lanced portion (110), a cut-out portion (112) defining a tab (124) and a suspension portion (114). The second portion (104) extends from the first portion (102) and configured to receive at least a portion of a flange of the ceiling framing member (400).
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
23.
A SOUND INSULATING ELEMENT AND A SUSPENDED CEILING SYSTEM
A sound insulating element includes a single body made of a mineral fibre material having acoustically insulating properties, the body including a front surface, a rear surface and a side surface connecting the front and rear surfaces. A suspended ceiling system to be suspended from a structural ceiling includes a plurality of ceiling tiles, and at least one of the ceiling tiles is a sound insulating element.
An acoustic panel made of a compressed mineral fibre material including two major surfaces and at least one side edge connecting the two major surfaces is provided. The panel has a perimeter region associated with the at least one side edge and delimiting a central region. The acoustic panel includes a first reinforcing structure having a strip-shaped extension across the inner boundary portion from a first position in the perimeter region to a second position in the perimeter region. Further a baseboard is provided.
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/28 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like having grooves engaging with horizontal flanges of the supporting construction or accessory means connected thereto
G10K 11/168 - Plural layers of different materials, e.g. sandwiches
B32B 19/04 - Layered products essentially comprising natural mineral fibres or particles, e.g. asbestos, mica next to another layer of a specific substance
B32B 3/06 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by features of form at particular places, e.g. in edge regions for securing layers togetherLayered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by features of form at particular places, e.g. in edge regions for attaching the product to another member, e.g. to a support
25.
A METHOD FOR INSTALLATION OF AN ACOUSTICAL SYSTEM IN A ROOM
The present invention relates to a method for installation of an acoustical system in a room of a building defined by structural surfaces, wherein the acoustical system is intended to be attached to at least one structural surface of the structural surfaces of the room, the method comprising acquiring a room geometry by scanning the room and/or by retrieving the room geometry data from a building information model (BIM), determining the acoustical characteristics of the structural surfaces defining the room, calculating, based on the acoustical characteristics and room geometry, a required acoustical characteristic of the acoustical system for obtaining a desired acoustical environment in the room, selecting acoustical elements for obtaining the required acoustical characteristics, creating an installation layout based on the selected acoustical elements, projecting, by means of a laser projector, an installation guiding projection, based on the installation layout, on the at least one structural surface for guiding the installation of the acoustical system.
G06F 30/12 - Geometric CAD characterised by design entry means specially adapted for CAD, e.g. graphical user interfaces [GUI] specially adapted for CAD
G06F 30/13 - Architectural design, e.g. computer-aided architectural design [CAAD] related to design of buildings, bridges, landscapes, production plants or roads
26.
A DEVICE, SYSTEM, AND METHOD FOR INSTALLATION OF AN ACOUSTICAL ELEMENT IN A ROOM
The present invention relates to a method for the installation of at least one acoustical element in a room of a building defined by structural surfaces, wherein the at least one acoustical element is intended to be attached to at least one structural surface of the structural surfaces of the room, the method comprising acquiring a room geometry, determining an acoustical characteristic of at least one structural surface defining the room geometry, selecting at least one acoustical element, based on the acoustical characteristic and room geometry, for obtaining a desired acoustical environment in the room, and projecting, by means of a laser projector, an installation guiding projection on the at least one structural surface for the at least one acoustical element for guiding the installation of the at least one acoustical element.
G06F 30/12 - Geometric CAD characterised by design entry means specially adapted for CAD, e.g. graphical user interfaces [GUI] specially adapted for CAD
G06F 30/13 - Architectural design, e.g. computer-aided architectural design [CAAD] related to design of buildings, bridges, landscapes, production plants or roads
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
Packing, stopping and insulating materials; materials made of mineral wool, wood wool, wood fibre, rock wool, glass fibre and glass wool for insulation, sound proofing and sound absorption; sound proofing materials; sound absorbing materials; insulating, sound proofing and sound absorbing materials in the form of panels, boards, wood slabs, wood ribs and slabs with or without facing; mineral wool, wood wool, wood fibre, rock wool, glass fibre and glass wool fabrics and paint for insulating, sound proofing and sound absorbing materials; coating materials for insulating, sound proofing and sound absorbing purposes. Non-metallic building materials, including building panels, building tiles, building slabs, ceilings, ceiling tiles, panels and slabs, wall panels, slabs, boards and tiles, claddings, linings and coatings for walls and ceilings in buildings; facings for building materials; partitions not of metal; building materials for coating walls and ceilings (other than paint); non-metallic coating materials (other than paints).
The present invention relates to a suspended ceiling system (100) including at least one profile (104a-c, 204, 304, 404) for supporting a ceiling tile (120), at least one suspension element (108, 208, 308, 408), and at least 5 one hanger (106, 206) for suspending the at least one profile (104a-c, 204, 304, 404). The suspension element (108, 208, 308, 408) includes a clamping section (210, 310, 410) and a suspension section (212, 312, 412). The clamping section (210, 310, 410) is configured to clamp the suspension element (208, 308, 408) on a bulb (232, 332, 432) of the profile (104a-c, 204, 10 304, 404). The clamping section (210, 310, 410) comprises an engagement element (214, 314, 414) and a clamping element (216, 316, 416). The engagement element (216, 316, 416) is configured for engagement with an undercut surface portion (236, 336, 436) of the bulb (232, 332, 432). The clamping element (216, 316, 416) is configured to clamp a top portion (238, 15 338, 438) of the bulb (232, 332, 432). Each hanger (106, 206) is configured to engage the suspension section (212, 312, 412) of an associated suspension element (108, 208, 308, 408).
E04B 9/18 - Means for suspending the supporting construction
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
A method for recycling mineral wool material (10), comprising fragmentizing the mineral wool material (10) for obtaining a fragmentised mineral wool material (20), wetting the fragmentised mineral wool (20) material with a liquid (22) comprising alkaline activators for obtaining a wetted mineral wool material (30), removing excess liquid (31; 3T) from the wetted mineral wool material (30) for obtaining a semi-dried mineral wool material (40), moulding the semi-dried mineral wool material (40) into a tile shaped element (1), and curing the tile shaped element (1).
A diffuse ceiling ventilation system (101; 201; 301, 401) for a flow of air from a plenum space (103) into a room (106) below a suspended ceiling (104; 204; 304). The diffuse ceiling ventilation system (101; 201; 301, 401) 5 comprises an air inlet (102) for providing air to the plenum space (103). The suspended ceiling (104; 204; 304) comprises a plurality of ceiling tiles (109; 209; 309, 409) and a grid of profiles (107; 207; 307) for supporting the plurality of ceiling tiles (109; 209; 309, 409). The grid of profiles (107; 207; 307) and/or the ceiling tiles (109; 209; 309, 409) are configured to form air 10 gaps (112; 212; 312, 412) allowing air to flow from the plenum space (103) to the room below (106). The air gaps (112; 212; 312, 412) are configured to have an increased air flow area as a function of increased distance from the air inlet (102), for providing a controlled flow of air through the suspended ceiling (104; 204; 304) into the room (106) below. The air gaps (212)15 comprise openings formed by ceiling tiles (209) spaced apart from the profiles (207) by spacer elements (220), the spacer elements (220) are configured to increase in height from one ceiling tile (209) to another ceiling tile (209) as the distance from the at least one air inlet (102) increases.
F24F 7/10 - Ventilation with ducting systems with forced air circulation, e.g. by fan with air supply, or exhaust, through perforated wall, floor or ceiling
E04B 9/02 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation having means for ventilation or vapour discharge
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
E04B 9/36 - Open-work ceilings, e.g. lattice type consisting of parallel slats
E04B 9/24 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like positioned on, or held against, horizontal flanges of the supporting construction
F24F 11/74 - Control systems characterised by their outputsConstructional details thereof for controlling the supply of treated air, e.g. its pressure for controlling air flow rate or air velocity
F24F 13/068 - Outlets for directing or distributing air into rooms or spaces, e.g. ceiling air diffuser formed as perforated walls, ceilings or floors
F24F 13/072 - Outlets for directing or distributing air into rooms or spaces, e.g. ceiling air diffuser of elongated shape, e.g. between ceiling panels
F24F 13/08 - Air-flow control members, e.g. louvres, grilles, flaps or guide plates
A method for manufacturing acoustical elements, includes providing a first fibre component in a form of mineral wool and a second fibre component in a form of bicomponent fibres having a core with a thermoplastic outer layer, mixing the first fibre component and the second fibre component, for provision of a mixture, shaping the mixture into single layered tile shaped elements whereby the mixture is compressed with a compression ratio to a compressed state, and fixating the single layered tile shaped elements in the compressed state for obtaining the acoustical elements.
The present invention relates to a method (300) for rendering a soundscape of a room. The method (300) comprising: obtaining (S302) dimensions of the room; obtaining (S304) current position and orientation of a user device in the room; assigning (S306) one or more surfaces of the room with respective acoustical properties; calculating (S310) the soundscape in the room based on one or more sound sources, the acoustical properties of the one or more surfaces of the room and the dimensions of the room; and rendering (S312) the soundscape of the room by generating a virtual representation of the soundscape with respect to the current position and orientation of the user device and overlaying the virtual representation of the soundscape on a video stream of the room on a screen of the user device thereby forming a completely or partially rendered representation of the soundscape of the room.
A connection element (100) for interconnecting a first profile (10) having an inverted T-shaped cross-section and an extension along a longitudinal direction (L) with a second profile (20) having an inverted T-shaped cross-section and an extension along a transversal direction (T), the second profile (20) crossing the extension (L) of the first profile (10) above the first profile (10).
E04B 9/16 - Connections between non-parallel members of the supporting construction the members lying in different planes
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
E04B 9/20 - Means for suspending the supporting construction adjustable
E04B 9/18 - Means for suspending the supporting construction
34.
DETERMINING AN AIRBORNE AND/OR AEROSOL PATHOGEN RISK EXPOSURE
A computer implemented method for determining an airborne and/or aerosol pathogen risk exposure includes determining an acoustical parameter for a portion of a building, recording, using a microphone in a mobile electronic device located in the portion of the building, sound pressure level over time originating from speech in the portion of the building, and determining the airborne and/or aerosol pathogens risk exposure as a function of the recorded sound pressure over time and the determined acoustical parameter.
G16H 50/30 - ICT specially adapted for medical diagnosis, medical simulation or medical data miningICT specially adapted for detecting, monitoring or modelling epidemics or pandemics for calculating health indicesICT specially adapted for medical diagnosis, medical simulation or medical data miningICT specially adapted for detecting, monitoring or modelling epidemics or pandemics for individual health risk assessment
G16H 50/80 - ICT specially adapted for medical diagnosis, medical simulation or medical data miningICT specially adapted for detecting, monitoring or modelling epidemics or pandemics for detecting, monitoring or modelling epidemics or pandemics, e.g. flu
H04W 4/021 - Services related to particular areas, e.g. point of interest [POI] services, venue services or geofences
An acoustical tile member (100) having a front surface (106) intended to face a room (300), an opposing rear surface (108) and four side surfaces (110, 110a) connecting the front surface (106) and the rear surface (108), the acoustical tile member (100) comprising a first layer (102) and a second layer (104), the first layer (102) being associated with the front surface (106) and comprises woodwool, wherein each of at least two opposing side surfaces (110) of the four side surfaces (110, 110a) is provided with a groove configuration (112) for mounting of the acoustical tile member (100).
The present invention relates to a tile element (102a-f, 202a) comprising a tile (102a-f, 202a) and an anchor element (106a-f, 206a) associated with only one surface (107a-f; 108a-f; 209a) of the tile (102a-f, 202a). The anchor element (106a-f, 206a) comprises a body (110a-f) supporting a wire lock (114a-f). The anchor element (106a-f, 206a) is arranged in the tile (102a-f, 202a) such that the anchor element (106a-f, 206a) and the wire lock (114a-f) thereof becomes recessed in the tile (102a-f, 202a) and such that an access port (118a-f) of the wire lock (114a-f) becomes accessible from said surface (107a-f; 108a-f; 209a) of the tile (102a-f, 202a). The anchor element (106a-f, 206a) is arranged in the tile (102a-f, 202a) by being molded, pressed or slotted into the tile (102a-f, 202a). A tile system (100, 200) including a tile element (102a-f, 202a) is also provided.
F16B 5/00 - Joining sheets or plates to one another or to strips or bars parallel to them
F16B 5/01 - Joining sheets or plates to one another or to strips or bars parallel to them by means of fastening elements specially adapted for honeycomb panels
F16B 13/02 - Dowels or other devices fastened in walls or the like by inserting them in holes made therein for that purpose in one piece with protrusions or ridges on the shaft
F16B 21/09 - Releasable fastening devices with a stud engaging a keyhole slot
E04B 9/00 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation
E04B 9/20 - Means for suspending the supporting construction adjustable
E04B 9/22 - Connection of slabs, sheets or the like to the supporting construction
E04B 9/36 - Open-work ceilings, e.g. lattice type consisting of parallel slats
37.
CEILING TILE AND SUSPENDED CEILING SYSTEM COMPRISING SUCH A CEILING TILE
A ceiling tile for a suspended ceiling system comprising a grid of profiles for supporting the ceiling tile, the ceiling tile comprises a front surface intended to face a room in an installed state of the ceiling tile and a plurality of spacer elements discretely distributed along a perimeter portion of the ceiling tile. The plurality of spacer elements is formed separately from the ceiling tile, wherein each spacer element comprises a body portion and an anchoring portion for attaching the body portion to the ceiling tile.
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
E04B 9/28 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like having grooves engaging with horizontal flanges of the supporting construction or accessory means connected thereto
A method is for installing a ceiling system attached to a structural ceiling surface. The method includes illuminating, in sequence and by a projector, different subsets of a set of optical sensors separately arranged in a known distribution pattern on the structural ceiling surface. Each optical sensor of the set of optical sensors is arranged to output a temporal signal indicative of a level of illumination. The method also includes determining an image plane relative to the projector based on the known distribution pattern of the set of optical sensors and the outputted temporal signals of each of the optical sensors, and displaying, by the projector, an image indicative of installation locations of the ceiling system at the image plane.
E04F 21/18 - Implements for finishing work on buildings for setting wall or ceiling slabs or plates
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
G01C 15/00 - Surveying instruments or accessories not provided for in groups
G06F 30/13 - Architectural design, e.g. computer-aided architectural design [CAAD] related to design of buildings, bridges, landscapes, production plants or roads
39.
A SECONDARY PROFILE CONNECTOR FOR A SUSPENDED CEILING SYSTEM
A secondary profile connector for a suspended ceiling system includes a secondary profile associated with the secondary profile connector and a primary profile having a web provided with an opening for reception of the secondary profile connector. The secondary profile connector includes a tongue arrangement insertable into the opening of the web of the primary profile for releasable connection of the secondary profile connector to the primary profile.
A suspended ceiling system includes a polygon-shaped ceiling tile and a grid of profiles supporting the ceiling tile, the grid of profiles defining a frame in which the ceiling tile is arranged and supported. The ceiling tile includes a front surface, a rear surface and at least three side edges extending between the front surface and the rear surface. A side edge portion associated with each side edge includes a top tongue, a bottom tongue, and a groove extending along the side edge portion and separating the top tongue and the bottom tongue. The top tongues include engagement surfaces resting on the supporting flanges of the grid of profiles, and a distal end of each top tongue extends beyond a distal end of the bottom tongue such that a bottom section of the ceiling tile is insertable from above into the frame.
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/24 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like positioned on, or held against, horizontal flanges of the supporting construction
41.
Suspended ceiling system and method for installing thereof
A suspended ceiling system (1) comprising a plurality of ceiling tiles and a grid (100) of profiles (40) for supporting the plurality of ceiling tiles, the grid (100) of profiles (40) comprising at least a first and a second profile (40) configured to be interconnected along a longitudinal axis, the first and second profile (40) each comprising two laterally extending flanges (43) and an upstanding web (44) provided with a bulb (41) at its free end, wherein each of the first and second profile (40) has a curved extension and is configured to be installed such that it, in an installed and unloaded condition, bulges in an upward direction.
E04B 9/18 - Means for suspending the supporting construction
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
42.
GRID OF PROFILES AND METHOD FOR DISMOUNTING A GRID OF PROFILES
A grid of profiles (10) for a suspended ceiling system, comprising a primary profile (100) having a web (108) provided with a connection opening (102), and a first and second secondary profile (200) each having an end provided with a hook-on member (210). The first and second secondary profiles (200) are connected to the primary profile (100) by means of the hook-on members (210) which are inserted into the connection opening (102) from opposite sides thereof for hooked engagement with the web (108) of the primary profile (100). The first and second secondary profiles (200) each comprises a lug (212) extending in the longitudinal direction (L2) of the associated first or second secondary profile (200), which lugs (212) cooperate with the primary profile (100) to define a mounted state of the grid of profiles (10). Each lug (212) is moveable around a folding axis (A1) arranged at angle (α) of 15° and 80°, preferably 45°, to the longitudinal direction (L2) of the respective first and second secondary profile (200). The invention also relates to a method for dismounting a grid of profiles.
E04B 9/08 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction having the capability of expansion
The present invention relates to an absorber tile element (102a-f, 202a) including an anchor element (106a-f) associated with one surface (107a-b, 107e-f; 108a-b, 108e-f; 209a) of the absorber tile element (102a-f, 202a). The anchor element (106a-f, 206a) comprises a head portion (110a-b, 110e-f) and a threaded portion (112a-b, 112e-f). The threaded portion (112a- b, 112e-f) being threaded into the absorber tile element such that the head portion (110a-b, 110e-f) becomes recessed in the absorber tile element (102a-f, 202a). The anchor element (106a-f, 206a) includes a wire lock (114a-b, 114e-f) arranged in the anchor element (106a-f, 206a) and having an access port (118a-b, 118e-f) accessible from a top side (116a-b, 116e-f) of the head portion (110a-b, 110e-f). A tile system including absorber tile element (102a-f, 202a) is also provided.
A grid of profiles (10) for a suspended ceiling system comprising: a primary profile (100) provided with a bulb portion (102) extending in a longitudinal direction of the primary profile (100), a secondary profile (200) comprising a connector (202) at an end of the secondary profile (200), and a connection clip (300) comprising a base portion (302) configured for mounting to the bulb portion (102) of the primary profile and a projecting flange (304) provided with an opening (306), the opening (306) being configured for reception of the connector (202) of the secondary profile (200) from a first side (304a) of the projecting flange (304) and also a connector (202) of an opposing secondary profile (200) from a second side (304b) of the projecting flange (304).
A sound insulating element (100) comprising a single body (102) made of a mineral fibre material having acoustically insulating properties, the body (102) comprising a front surface (104), a rear surface (106) and a side surface (108) connecting the front (104) and rear (106) surfaces and a suspended ceiling system (10) configured to be suspended from a structural ceiling (20), the suspended ceiling system (10) comprising a plurality of ceiling tiles (11), wherein at least one ceiling tile (11) is a sound insulating element (100).
DEVICE FOR UNILATERAL COUPLING OF AN ELONGATED SUPPORT STRUCTURE TO A PROFILE OF A GRID OF PROFILES IN A SUSPENDED CEILING SYSTEM AND SUSPENDED CEILING SYSTEM
The present invention relates to a device (200, 300) for unilateral coupling of an elongated support structure (106, 106a-c, 220, 220a-c, 320) to a profile (103) of a grid of profiles (102) in a suspended ceiling system (100). The device (200, 300) comprises a first section (202, 302) connectable to the profile (103) of the grid of profiles (102). The first section (202, 302) is configured to be mounted over an upper bulb (103b) of the profile (103). The device (200, 300) comprises a second section (204, 304) configured to extend at an oblique angle relative to a mounting plane of the suspended ceiling system (100). The device (200, 300) comprises a single hole configuration (206, 306) adapted to receive an end portion of the support structure (106, 106a-c, 220, 220a-c, 320). The device (200, 300) is configured to be arranged above a lateral support flange (103c) of the profile (103) when the device (200, 300) is connected to the profile (103). A suspended ceiling system (100) comprising the device (200, 300) is also disclosed.
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
Packing, stopping and insulating materials; materials made of mineral wool and glass wool for insulation, sound proofing and sound absorption; sound proofing materials; sound absorbing materials; insulating, sound proofing and sound absorbing materials in the form of panels and slabs with or without facing; mineral wool and glass wool fabrics and paint for insulating, sound proofing and sound absorbing materials; coating materials for insulating, sound proofing and sound absorbing purposes. Non-metallic building materials, including building panels, building tiles, building slabs, ceilings, ceiling tiles, panels and slabs, wall panels, slabs and tiles, claddings, linings and coatings for walls and ceilings in buildings; facings for building materials; partitions not of metal; building materials for coating walls and ceilings (other than paint); non-metallic coating materials (other than paints).
48.
AN ACOUSTIC PANEL, A SUSPENDED ACOUSTIC SYSTEM USING SUCH ACOUSTIC PANEL, AND A BASEBOARD
An acoustic panel made of a compressed mineral fibre material comprising two major surfaces (2) and at least one side edge (3) connecting the two major surfaces (2) is provided. The panel (1) has an perimeter region (5) associated with the at least one side edge and delimiting a central region (7). The acoustic panel (1) comprises a first reinforcing structure (8) having a strip-shaped extension across the inner boundary portion (7) from a first position (A) in the perimeter region (5) to a second position (B) in the perimeter region (5). Further a baseboard (100) is provided.
E04B 9/28 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like having grooves engaging with horizontal flanges of the supporting construction or accessory means connected thereto
A system for recycling planar objects including compressed mineral fiber material includes: a conveyor arranged to covey the planar objects through a number of stations at least including a thickness measurement station and a sound measurement station. The sound measurement station includes a sound reflecting surface arranged to back a first major surface of a planar object, a sound emitter arranged to emit sound towards the sound reflecting surface, a sound receiver arranged to receive sound reflected from the sound reflecting surface, and a converter arranged to determine a property related to sound absorption. A sorting station is arranged to sort the planar objects based on determined properties in to a plurality of fractions.
A building system includes a building space defined by a structural ceiling and a flooring of a building, and a ceiling system. The ceiling system includes an air permeable suspended ceiling arranged below the structural ceiling, and a plenum space is formed between the suspended ceiling and the structural ceiling and a flooring space is formed between the flooring and the suspended ceiling. A plurality of partition wall sections is arranged in the plenum space extending between the structural ceiling and the suspended ceiling and forms a plurality of plenum modules distributed across the plenum space. Each plenum module includes equipment. The equipment of each plenum module includes a supply air device for delivery of supply air to the associated plenum module for pressurization thereof such that the supply air delivered to the plenum module is supplied to the flooring space through the air permeable suspended ceiling.
E04B 9/02 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation having means for ventilation or vapour discharge
E04B 2/72 - Walls of elements of relatively thin form
E04B 9/00 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation
A method (1000) for manufacturing acoustical elements (100), comprising providing (1002) a first fibre component (102) in the form of mineral wool and a second fibre component (104) in the form of bicomponent fibres having a core with a thermoplastic outer layer, mixing (1004) the first fibre component (102) and the second fibre component (104), for provision of a mixture (1), shaping (1006) the mixture (1) into single layered tile shaped elements (2) whereby the mixture (1) is compressed with a compression ratio to a compressed state, and fixating (1008) the single layered tile shaped elements (2) in the compressed state for obtaining the acoustical elements (100).
E04B 1/74 - Heat, sound or noise insulation, absorption, or reflectionOther building methods affording favourable thermal or acoustical conditions, e.g. accumulating of heat within walls
52.
DETERMINING AN AIRBORNE AND/OR AEROSOL PATHOGEN RISK EXPOSURE
The present invention relates to a computer implemented method for determining an airborne and/or aerosol pathogen risk exposure. The method comprising: determining an acoustical parameter for a portion of a building; recording, by means of a microphone in a mobile electronic device located in the portion of the building, sound pressure level over time originating from speech in the portion of the building; and determining the airborne and/or aerosol pathogens risk exposure as a function of the recorded sound pressure over time and the determined acoustical parameter.
G16H 50/30 - ICT specially adapted for medical diagnosis, medical simulation or medical data miningICT specially adapted for detecting, monitoring or modelling epidemics or pandemics for calculating health indicesICT specially adapted for medical diagnosis, medical simulation or medical data miningICT specially adapted for detecting, monitoring or modelling epidemics or pandemics for individual health risk assessment
G16H 50/80 - ICT specially adapted for medical diagnosis, medical simulation or medical data miningICT specially adapted for detecting, monitoring or modelling epidemics or pandemics for detecting, monitoring or modelling epidemics or pandemics, e.g. flu
An acoustic system (100) for improving the acoustic quality in a room (102) for speech, the acoustic system (100) comprising a room (102) having a first zone (A) and a second zone (B), the system further comprising a ceiling (104) of the room (102), the ceiling (104) comprising a plurality of ceiling tiles (110, 112), wherein the ceiling tiles comprises a first group of ceiling tiles (110) having sound absorbing properties and a second group of ceiling tiles (112) having sound diffusing properties.
3, a porosity in the range of 0.75-0.99 and a thickness in the range of 5-75 mm. The ground mineral wool may be ground glass or stone wool and the fibre component may be a wood fibre component, a polymer fibre component and/or a mineral wool component. Further, a geopolymer mixture is provided upon recycling mineral wool which is ground to powder and mixed with an alkali activator component. Additionally, a method for producing acoustical geopolymer panel elements includes grinding elements including mineral wool for provision of a powder component.
C04B 28/00 - Compositions of mortars, concrete or artificial stone, containing inorganic binders or the reaction product of an inorganic and an organic binder, e.g. polycarboxylate cements
C04B 40/00 - Processes, in general, for influencing or modifying the properties of mortars, concrete or artificial stone compositions, e.g. their setting or hardening ability
The present invention relates to a method (700) for installation of a ceiling system. The method comprising: In sequence illuminating (702), by a projector (104), different sub sets of a set of optical sensors (112a-d, 212a-d, S1, S2) separately arranged in a known distribution pattern on a structural ceiling surface (102). Each optical sensor (112a-d, 212a-d, S1, S2) of the set of optical sensors (112a-d, 212a-d, S1, S2) being arranged to output a temporal signal (TS1, TS2) indicative of a level of illumination. Determining (704) an image plane relative to the projector (104) based on the known distribution pattern and the outputted temporal signals (TS1, TS2) of each of the optical sensors (112a-d, 212a-d, S1, S2). Displaying (706), by the projector (104), an image (122, 222, 322) indicative of installation locations (120, 220) of the ceiling system at the image plane.
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
56.
CEILING TILE AND SUSPENDED CEILING SYSTEM COMPRISING SUCH A CEILING TILE
A ceiling tile (100) for a suspended ceiling system (200) comprising a grid of profiles (300) for supporting the ceiling tile (100), the ceiling tile (100) comprises a front surface (102) intended to face a room (10) in an installed state of the ceiling tile (100) and a plurality of spacer elements (20) discretely distributed along a perimeter portion (106) of the ceiling tile (100). The plurality of spacer elements (20) is formed separately from the ceiling tile (100), wherein each spacer element (20) comprises a body portion (22) and an anchoring portion (24) for attaching the body portion (22) to the ceiling tile (100).
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/02 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation having means for ventilation or vapour discharge
A method for coating a tile element includes providing a tile element made of a compressed fibre material having a porosity in the range of 0.92-0.99 and applying a water-based coating material to a side edge surface of the tile element extending between two opposite major surfaces of the tile element. The applying is performed by an applicator head of a continuous vacuum coating apparatus that applies the water-based coating material to the side edge surface of the tile element and removes excess through a vacuum. The water-based coating material is applied at a feeding rate of the tile element relative the applicator head in the range of 25-150 m/min. The water-based coating material forms a coating layer including an outer coating layer and an inner coating layer penetrating the side edge surface. The inner coating layer has penetration depth of at least 100 μm.
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05D 3/02 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials by baking
B05D 3/04 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials by exposure to gases
58.
A SECONDARY PROFILE CONNECTOR FOR A SUSPENDED CEILING SYSTEM
A secondary profile connector (100) for a suspended ceiling system (1000) comprising a secondary profile (300) associated with the secondary profile connector (100) and a primary profile (200) having a web (202) provided with an opening (204) for reception of the secondary profile connector (100), the secondary profile connector (100) comprising a tongue arrangement (102) insertable into the opening (204) of the web (202) of the primary profile (200) for releasable connection of the secondary profile connector (100) to the primary profile (200).
A suspended ceiling system comprising a polygon-shaped ceiling tile (10) and a grid of profiles (30) supporting the ceiling tile (10), the grid of profiles (30) defining a frame (31) in which the polygon-shaped ceiling tile (10) is arranged and supported by supporting flanges (32) of the grid of profiles (30). The polygon-shaped ceiling tile (10) comprises at front surface (11), a rear surface (12) and at least three side edges (13) extending between the front surface (11) and the rear surface (12), wherein a side edge portion associated with each side edge (13) comprises a top tongue (14), a bottom tongue (15), and a groove (16) extending along the side edge portion and separating the top tongue (14) and the bottom tongue (15). The top tongues (14) comprise engagement surfaces (18) resting on the supporting flanges (32) of the grid of profiles (30), and a distal end (19) of each top tongue (14) extends beyond a distal end (20) of the bottom tongue (15) such that a bottom section (21) of the polygon-shaped ceiling tile (10) comprising the bottom tongue (15) and the groove (16) of each side edge portion is insertable from above into the frame (31) defined by the grid of profiles (30).
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/24 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like positioned on, or held against, horizontal flanges of the supporting construction
E04B 9/28 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like having grooves engaging with horizontal flanges of the supporting construction or accessory means connected thereto
60.
SUSPENDED CEILING SYSTEM AND METHOD FOR INSTALLING THEREOF
A suspended ceiling system (1) comprising a plurality of ceiling tiles and a grid (100) of profiles (40) for supporting the plurality of ceiling tiles, the grid (100) of profiles (40) comprising at least a first and a second profile (40) configured to be interconnected along a longitudinal axis, the first and second profile (40) each comprising two laterally extending flanges (43) and an upstanding web (44) provided with a bulb (41) at its free end, wherein each of the first and second profile (40) has a curved extension and is configured to be installed such that it, in an installed and unloaded condition, bulges in an upward direction.
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
E04B 9/10 - Connections between parallel members of the supporting construction
An absorber tile element includes compressed mineral fiber material and has a first major surface, an opposing second major surface and at least one side edge surface, and an anchor element associated with one of the first and second major surface or one of the at least one side edge surfaces. The anchor element includes a head portion and a threaded portion, the head portion defining an open cavity facing a top surface. An engagement member is arranged in the cavity, and arranged to engage with a hook element. The threaded portion is threaded into the absorber tile element such that the head portion becomes substantially recessed in the absorber tile element. A corresponding tile system can includes the absorber tile element.
The present invention relates to a ceiling system (100). The system (100) includes a supporting structure (102) having a plurality of main runners (104a-e) made of an electrically conductive material. The main runners (104a- e) are arranged such that a first space (106) is formed between at least one main runner (104b) and a first adjacent main runner (104a) and a second space (108) is formed between the at least one main runner (104b) and a second adjacent main runner (104c). An electric device (110, 110a, 112) is supported by the main runners (104a-e) and is arranged in the first (106) or second space (108). A power source is (114) arranged to apply an electric voltage (V) between the main runners (104a-e). The electric device (110, 110a, 112) comprises connectors (116, 118) being in electric contact with the main runners (104a-e) such that the electric device (110, 112) is powered by the applied electric voltage (V).
E04B 9/00 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
Packing, stopping and insulating materials; materials made of mineral wool, glass wool, stone wool, wood wool, glass fibres and rock fibres; mineral wool, glass wool, stone wool, wood wool, glass fibres and rock fibres for insulation, sound proofing and sound absorption; sound proofing materials; sound absorbing materials; insulating, sound proofing and sound absorbing materials in the form of panels and slabs with or without facing; coating materials and paint for insulation, sound proofing and sound absorbing purposes; products made of semi-processed plastics; all aforementioned good not including adhesives. Non-metallic building materials, including building panels, building tiles, building slabs, ceilings, ceiling tiles, panels and slabs, wall panels, slabs and tiles, claddings, linings and coatings for walls and ceilings in buildings; facings for building materials; partitions not of metal; non-metallic latticework, runners, hangers, profiles, trims, splices and clips for suspended ceilings and walls; parts and fittings for all aforesaid goods, not included in other classes; building materials for coating walls and ceilings (other than paint); non-metallic coating materials (other than paints).
64.
Profile member and method for manufacturing thereof
A method for manufacturing a profile member for a suspended ceiling system, comprising forming a sheet metal material into an elongate T-shaped profile member with a web having two web side walls and a pair of oppositely disposed flanges projecting from a bottom portion of the web, and laser welding the elongate T-shaped profile member for providing a laser weld joint extending in a longitudinal direction of the T-shaped profile member and joining the two web side walls to each other. The step of laser welding comprises alternatingly performing a first operation and a second operation, the second operation being different from the first operation, whereby a laser weld joint is provided comprising along its extension alternating welded first sections associated to the first operation and second sections associated to the second operation. The present invention also relates to an elongate profile member provided with a laser weld joint.
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
B23K 26/262 - Seam welding of rectilinear seams of longitudinal seams of tubes
The present invention relates to a system (100) for recycling planar objects (102, 102a-e) comprising compressed mineral fiber material. The system (100) comprising: a conveyor (108) arranged to covey the planar objects (102, 102a-e) through a number of stations (110, 110x, 112, 112x, 114, 116) at least comprising: A thickness measurement station (110, 110x) and a sound measurement station (112, 112x). The sound measurement station (112, 112x) comprising, a sound reflecting surface (120) arranged to back a first major surface of a planar object (102, 102a-e), a sound emitter (122) arranged to emit sound towards the sound reflecting surface (120), a sound receiver (124) arranged to receive sound reflected from the sound reflecting surface (120), and a converter (126) arranged to determine a property related to sound absorption. A sorting station (116) is arranged to sort the planar objects (102, 102a-e) based on determined properties in to a plurality of fractions (116a-d, 116w). A corresponding method (200) is also disclosed.
A building system comprising a building space defined by a structural ceiling (2) and a flooring (3) of a building, and a ceiling system (4). The ceiling system (4) comprises an air permeable suspended ceiling (5) arranged below the structural ceiling (2), wherein a plenum space (7) is formed between the suspended ceiling (5) and the structural ceiling (2) and a flooring space (8) is formed between the flooring (3) and the suspended ceiling (5), and a plurality of partition wall sections (6). The plurality of partition wall sections (6) is arranged in the plenum space (7) extending between the structural ceiling (2) and the suspended ceiling (5); and forms a plurality of plenum modules (9) distributed across the plenum space (7). Each one of the plurality of plenum modules (9) comprises equipment, the equipment of each plenum module (9) comprising a supply air device (12) for delivery of supply air to the associated plenum module (9) for pressurization thereof such that the supply air delivered to the plenum module (9) is supplied to the flooring space (8) through the air permeable suspended ceiling (5).
E04B 9/02 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation having means for ventilation or vapour discharge
The inventive concept relates to a planar suspended ceiling system comprising: a ceiling tile (10) having a front side (1), a rear side (2) and at least one side edge extending between the front side (1) and the rear side (2), the ceiling tile (10) comprising an acoustical absorbing body (4), and a front cover (3) arranged at the front side (1) of the ceiling tile (10); wherein a slit (5) is provided extending across the entire rear side (2) of the acoustical absorbing body (4) thereby dividing said acoustical absorbing body (4) into a first and a second body section (4a, 4b), and having a depth such that the ceiling tile (10) is foldable along the slit (5) with the front cover (3) acting as a joint; wherein opposing portions of the at least one side edge are provided with each a groove (6) and; a grid of profiles (11) for supporting said ceiling tile (10) in a planar, non-folded state in which flanges (7) of the grid of profiles (11) extend into the grooves (6) thereby supporting the ceiling tile (10).
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/28 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like having grooves engaging with horizontal flanges of the supporting construction or accessory means connected thereto
An acoustic and illuminating ceiling panel includes a layer of acoustic absorbent material, the layer including a main inner face intended to be pointed toward the inside of the room, and light sources on the main inner face that is optionally covered by a voile fabric and/or coated, with a paint, wherein the light sources include organic light-emitting diode (OLED) modules with a luminous efficacy greater than or equal to 60 lm/W, and wherein a number and size of the OLED modules are adapted so that the ceiling panel provides an acoustic absorption coefficient αw greater than or equal to 0.7.
F21S 8/02 - Lighting devices intended for fixed installation of recess-mounted type, e.g. downlighters
E04B 9/00 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/28 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like having grooves engaging with horizontal flanges of the supporting construction or accessory means connected thereto
E04B 9/32 - Translucent ceilings, i.e. permitting both the transmission and diffusion of light
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
An acoustical geopolymer panel element comprising a layer comprising a fibre component and a geopolymer binder made from a mixture comprising ground mineral wool, and an additional layer comprising mineral wool, wherein the layer comprising a fibre component and a geopolymer binder has a density in the range of 20 - 400 kg/m3, a porosity in the range of 0,75 - 0,99 and a thickness in the range of 5 - 75 mm. The ground mineral wool may be ground glass or stone wool and the fibre component may be a wood fibre component, a polymer fibre component and/or a mineral wool component. Further described is the provision of a geopolymer mixture upon recycling mineral wool which is ground to powder and mixed with an alkali activator component. The invention also relates to a method for producing acoustical geopolymer panel elements which comprises the step of grinding elements comprising mineral wool for provision of a powder component.
C04B 28/00 - Compositions of mortars, concrete or artificial stone, containing inorganic binders or the reaction product of an inorganic and an organic binder, e.g. polycarboxylate cements
A method for coating a tile element (1), comprising providing a tile element (1) made of a compressed fibre material having a porosity in the range of 0,92 - 0,99, the tile element (1) having two opposite major surfaces (2), and applying a water-based coating material to a side edge surface (3) of the tile element (1) extending between the two opposite major surfaces (2). The step of applying the water-based coating material is performed by means of an applicator head (20) of a continuous vacuum coating apparatus (21), the applicator head (20) being configured to apply the water-based coating material to the side edge surface (3) of the tile element (1) and to remove excess of the water-based coating material through a vacuum, wherein the water-based coating material is applied at a feeding rate of the tile element (1) relative the applicator head (20) in the range of 25 -150 m/min. The water- based coating material forms a coating layer (50) comprising an outer coating layer (51) and an inner coating layer (52) penetrating the side edge surface (3). The inner coating layer (52) has penetration depth P1 of at least 100 μm and preferably in the range of 100-4000 μm.
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05D 3/02 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials by baking
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05D 3/04 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials by exposure to gases
The present invention relates to an absorber tile element (102a-f, 202a, 302a) comprising compressed mineral fiber material and having a first major surface (107a-b, 107e-f, 207a), an opposing second major surface (108a-b, 108e-f, 308a) and at least one side edge surface (109a-f, 209a, 309a), and an anchor element (106a-f) associated with one of the first and second major surface or one of the at least one side edge surfaces. The anchor element (106a-f, 206a, 306a) comprises a head portion (110a-b, 110e-f) and a threaded portion (112a-b, 112e-f), the head portion (110a-b, 110e-f) defining an open cavity (114a-b, 114e-f) facing a top surface (116a-b, 116e-f), wherein an engagement member (118a-b, 118e-f) is arranged in the cavity (114a-b, 114e-f), and configured for engagement with a hook element (124a-b, 124e- f). The threaded portion (112a-b, 112e-f) is threaded into the absorber tile element (102a-f) such that the head portion (110a-b, 110e-f) becomes substantially recessed in the absorber tile element (102a-f, 202a, 302a). A corresponding tile system is also provided.
A method for recycling of tile material (10) comprising compressed mineral fibre material and being in the form of at least one of waste material generated during manufacturing of tiles, residual material generated during installation of tiles, and tiles obtained from installed tile systems after end of life, comprising collecting the tile material (10), conversion of the tile material (10) into a plurality of body members (12), assembling a finite baseboard (30) by arranging the plurality of body members (12) on a carrier layer (31) and fixing them thereto, and conversion of the baseboard (30) into at least two tiles (33).
E04F 15/10 - Flooring or floor layers composed of a number of similar elements of other materials, e.g. fibrous or chipped materials, organic plastics, magnesite, hardboard
E04F 13/16 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements of fibres or chips, e.g. bonded with synthetic resins
E04F 13/18 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements of organic plastics with or without reinforcements or filling materials
B32B 19/00 - Layered products essentially comprising natural mineral fibres or particles, e.g. asbestos, mica
E04F 15/022 - Flooring consisting of parquetry tiles on a non-rollable sub-layer of other material, e.g. board, concrete, cork
B32B 19/04 - Layered products essentially comprising natural mineral fibres or particles, e.g. asbestos, mica next to another layer of a specific substance
B32B 37/12 - Methods or apparatus for laminating, e.g. by curing or by ultrasonic bonding characterised by using adhesives
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
B27M 3/00 - Manufacture or reconditioning of specific semi-finished or finished articles
74.
Device and method for suspension of a suspended ceiling and a suspended ceiling
A device for suspension of a suspended ceiling, comprising an elongated suspension member (3) having a first end (10) and an opposing second end (11), an anchoring head (4) being arranged at the first end (10); a housing (2) having an open top side (5) and an opposed, closed bottom side (6), the (2) housing defining a housing cavity (7) adapted to be filled with an adhesive (16); and a suspension member holder (8). A passage (9) is provided extending through the closed bottom side (6) of the housing (2), wherein the elongated suspension member (3) in an assembled state of the device extends through the passage (9) with the first end (10) positioned inside the housing cavity (7) and the second end (11) positioned outside the housing cavity (7) and wherein the suspension member holder (8) in the assembled state of the device positions the first end (10) and the thereto arranged anchoring head (4) of the suspension member (3) at a distance H1 from the closed bottom side (6). The invention also relates to a suspended ceiling system comprising such a device as well as a method for suspending a suspended ceiling in a structural ceiling.
A method for manufacturing a profile member (1) for a suspended ceiling system, comprising forming a sheet metal material into an elongate T- shaped profile member (1) with a web (2) having two web side walls (7a, 7b) and a pair of oppositely disposed flanges (3) projecting from a bottom portion (4) of the web (2), and laser welding the elongate T-shaped profile member (1) for providing a laser weld joint (8) extending in a longitudinal direction (L1) of the T-shaped profile member (1) and joining the two web side walls (7a, 7b) to each other. The step of laser welding comprises alternatingly performing a first operation and a second operation, the second operation being different from the first operation, whereby a laser weld joint (8) is provided comprising along its extension alternating welded first sections (11) associated to the first operation and second sections (12) associated to the second operation. The present invention also relates to an elongate profile member provided with a laser weld joint (8).
B23K 26/0622 - Shaping the laser beam, e.g. by masks or multi-focusing by direct control of the laser beam by shaping pulses
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
06 - Common metals and ores; objects made of metal
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
Metal building materials; ceilings of metal, building boards, panels, plates and tiles of metal; wall claddings, coverings and linings of metal for walls (buildings); grid systems of metal for ceilings; suspension systems of metal for ceilings; grids, rails, hangers, profile sections, cornices, joints and clips of metal for ceilings and walls; parts and fittings for all the aforesaid goods (not included in other classes). Packing, stopping and insulating materials; materials made of mineral wool, glass wool, fibre glass, glass fibres and rock fibres; mineral wool, glass wool, fibre glass, glass fibres and rock fibres for insulation, sound proofing and sound absorption; sound proofing materials; sound absorbing materials; insulating, sound proofing and sound absorbing materials in the form of panels and slabs with or without facing; insulating, sound proofing and sound absorption tape and band; metal foils for insulation, sound proofing and sound absorption; mineral wool, glass wool, fibre glass, glass fibres and rock fibres fabrics and paint for insulating, sound proofing and sound absorbing materials; sound transparent woven material; acoustic transparent woven material; coating materials for insulation, sound proofing and sound absorbing purposes; coating materials for insulating, sound proofing and sound absorbing purposes; products made of semi-processed plastics. Non-metallic building materials, including building panels, building tiles, building slabs, ceilings, ceiling tiles, panels and slabs, wall panels, slabs and tiles, claddings, linings and coatings for walls and ceilings in buildings; facings for building materials; partitions not of metal; non-metallic latticework, runners, hangers, profiles, trims, splices and clips for suspended ceilings and walls; parts and fittings for all aforesaid goods, not included in other classes; building materials for coating walls and ceilings (other than paint); non-metallic coating materials (other than paints).
The present invention relates to a surface forming system intended to be supported by a structural ceiling and/or a wall of a room. The surface forming system comprises a first tile and a second tile, each tile comprising a front major surface, an opposing back major surface and at least one edge surface extending along the perimeter of the tile and connecting the front and back major surfaces, a first connecting member and a second connecting member, each comprising a tile connector and a pivot connector, wherein the tile connector of the first connecting member and the second connecting member are connected to the first tile and the second tile, respectively, and wherein the pivot connector of the first and the second connecting members are pivotably connected to each other such that the tiles are foldable relative each other. The invention further relates to a method for installation of a surface forming system supported by a structural ceiling and/or wall of a room.
E04B 9/32 - Translucent ceilings, i.e. permitting both the transmission and diffusion of light
E04B 9/28 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like having grooves engaging with horizontal flanges of the supporting construction or accessory means connected thereto
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Education and instruction; tutoring; arranging of conferences and seminars. Research and development services; scientific and industrial research; product development.
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
Goods & Services
Education and instruction; tutoring; arranging of conferences and seminars. Research and development services; scientific and industrial research; product development.
81.
DEVICE AND METHOD FOR SUSPENSION OF A SUSPENDED CEILING AND A SUSPENDED CEILING
A device for suspension of a suspended ceiling, comprising an elongated suspension member (3) having a first end (10) and an opposing second end (11), an anchoring head (4) being arranged at the first end (10); a housing (2) having an open top side (5) and an opposed, closed bottom side (6), the (2) housing defining a housing cavity (7) adapted to be filled with an adhesive (16); and a suspension member holder (8). A passage (9) is provided extending through the closed bottom side (6) of the housing (2), wherein the elongated suspension member (3) in an assembled state of the device extends through the passage (9) with the first end (10) positioned inside the housing cavity (7) and the second end (11) positioned outside the housing cavity (7) and wherein the suspension member holder (8) in the assembled state of the device positions the first end (10) and the thereto arranged anchoring head (4) of the suspension member (3) at a distance H1 from the closed bottom side (6). The invention also relates to a suspended ceiling system comprising such a device as well as a method for suspending a suspended ceiling in a structural ceiling.
A cross runner connector for a suspended ceiling system (1) comprising a main runner (10) being provided with an opening (11) for reception of the cross runner connector and having a circumference defining an opening notch (12); and a cross runner (30), the cross runner connector comprising a guiding lip (41) and a locking lip (42) separated by a slit (43) and extending in the longitudinal direction (P2) of the cross runner connector, the guiding lip (41) having a guide edge portion (44) provided with a guide lip notch (45) and a distal guide tip (46) being offset in a first lateral direction (P3) such that the cross runner connector is laterally displaceable in the first lateral direction (P3) in response to insertion of the cross runner connector into the opening (11) of the main runner (10) with the guide edge portion (44) positioned in the opening notch (12) of the opening (11), and the locking lip (42) having a locking protrusion (48) protruding in the first lateral direction (P3). The invention further relates to a cross runner connector arrangement comprising the cross runner connector and a main runner.
The claimed invention describes a method of preparing an installation of a 3-dimensionally extending false ceiling or wall. The claimed method includes calculating format, position and orientation for each individual flat tile in the suspended ceiling or wall, associating each individual flat tile with a unique tile identity, producing the individual flat tiles according to the calculated format, providing respective flat tile with the tile identity of respective tile, and providing a representation of the 3-dimensionally extending suspended ceiling or wall including an association of the position of respective flat tile with respective tile identity.
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/36 - Open-work ceilings, e.g. lattice type consisting of parallel slats
E04B 9/22 - Connection of slabs, sheets or the like to the supporting construction
E04F 13/16 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements of fibres or chips, e.g. bonded with synthetic resins
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
42 - Scientific, technological and industrial services, research and design
Goods & Services
Packing, stopping and insulating materials; materials made of mineral wool, glass wool, fibre glass, glass fibres and rock fibres; mineral wool, glass wool, fibre glass, glass fibres and rock fibres for insulation, sound proofing and sound absorption; sound proofing materials; sound absorbing materials; insulating, sound proofing and sound absorbing materials in the form of panels and slabs with or without facing; insulating, sound proofing and sound absorption tape and band; metal foils for insulation, sound proofing and sound absorption; mineral wool, glass wool, fibre glass, glass fibres and rock fibres fabrics and paint for insulating, sound proofing and sound absorbing materials; coating materials for insulation, sound proofing and sound absorbing purposes; coating materials for insulating, sound proofing and sound absorbing purposes; products made of semi-processed plastics. Non-metallic building materials, including building panels, building tiles, building slabs, ceilings, ceiling tiles, panels and slabs, wall panels, slabs and tiles, claddings, linings and coatings for walls and ceilings in buildings; facings for building materials; partitions not of metal; non-metallic latticework, runners, hangers, profiles, trims, splices and clips for suspended ceilings and walls; parts and fittings for all aforesaid goods, not included in other classes; building materials for coating walls and ceilings (other than paint); non-metallic coating materials (other than paints). Licensing of intellectual property rights; licensing of packing, stopping and insulating materials; materials made of mineral wool, glass wool, fibre glass, glass fibres and rock fibres; mineral wool, glass wool, fibre glass, glass fibres and rock fibres for insulation, sound proofing and sound absorption; sound proofing materials; sound absorbing materials; insulating, sound proofing and sound absorbing materials in the form of panels and slabs with or without facing; insulating, sound proofing and sound absorption tape and band; metal foils for insulation, sound proofing and sound absorption; mineral wool, glass wool, fibre glass, glass fibres and rock fibres fabrics and paint for insulating, sound proofing and sound absorbing materials; coating materials for insulation, sound proofing and sound absorbing purposes; coating materials for insulating, sound proofing and sound absorbing purposes; products made of semi-processed plastics; non-metallic building materials, including building panels, building tiles, building slabs, ceilings, ceiling tiles, panels and slabs, wall panels, slabs and tiles, claddings, linings and coatings for walls and ceilings in buildings; facings for building materials; partitions not of metal; non-metallic latticework, runners, hangers, profiles, trims, splices and clips for suspended ceilings and walls; parts and fittings for all aforesaid goods, not included in other classes; building materials for coating walls and ceilings (other than paint); non-metallic coating materials (other than paints).
The present invention relates to a surface forming system intended to be supported by a structural ceiling and/or a wall of a room. The surface forming system comprises a first tile and a second tile, each tile comprising a front major surface, an opposing back major surface and at least one edge surface extending along the perimeter of the tile and connecting the front and back major surfaces, a first connecting member and a second connecting member, each comprising a tile connector and a pivot connector, wherein the tile connector of the first connecting member and the second connecting member are connected to the first tile and the second tile, respectively, and wherein the pivot connector of the first and the second connecting members are pivotably connected to each other such that the tiles are foldable relative each other. The invention further relates to a method for installation of a surface forming system supported by a structural ceiling and/or wall of a room.
06 - Common metals and ores; objects made of metal
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
[ Building materials of metal, namely, ceilings of metal, metal building boards, panels, plates and tiles of metal, wall claddings and wall linings of metal, ceiling supports of metal, suspension systems of metal for ceilings comprising panels, latticework of metal, runners of metal for sliding doors, metal picture hangers, metal profiles, metal trims for suspended ceilings and walls, clips of metal for suspended ceilings and walls, parts for all the aforesaid goods ] [ Packing and insulating materials; Building insulation material, namely, mineral wool, glass wool, glass fibres, and rock fibres in the nature of diatomite; Mineral wool, glass wool, glass fibres and rock fibres in the nature of diatomite for insulation, sound proofing and sound absorption; Sound absorbing materials, namely, sound absorbing flooring underlayment; Insulating, sound proofing and sound absorbing materials in the form of panels and slabs with or without facing; Insulating, sound proofing and sound absorption tape; Metal foils for insulation, sound proofing and sound absorption; Mineral wool, glass wool, glass fibres, and rock fibres in the nature of diatomite, fabrics and paint for insulating, sound proofing and sound absorbing materials; Exterior wall insulation base coat attached to a building substrate for forming an exterior surface of the building for insulating and insulation, sound proofing and sound absorbing purposes ] Non-metallic building materials, namely, non-metal building panels, non-metal building tiles, non-metal building slabs of glass wool, non-metal ceiling panels, non-metal ceiling tiles, non-metal wall panels and non-metal slabs of glass wool, non-metal wall panels, non-metal slabs of glass wool and non-metal tiles, wall claddings not of metal, linings and coatings for walls and ceilings in buildings not of metal; Suspension systems for ceilings not of metal comprising panels; Facing sheets of plywood; partitions not of metal for buildings; Non-metallic latticework, runners not of metal for sliding doors, non-metal picture hangers, non-metal profiles, non-metal trims for suspended ceilings and walls, non-metal clips for suspended ceilings and walls; Parts and fittings for all aforesaid goods, not included in other classes; Building materials for coating walls and ceilings, namely, water based acrylic sealer coatings for use on ceilings and wall panels, excluding paints; Building materials in the nature of non-metallic coatings, excluding paints, namely, water based acrylic sealer coating for use on ceilings and wall panels; Glass wool ceiling panels and glass wool wall panels for use in absorbing sound
There is disclosed a transport unit (100) comprising at least one secondary pack (200), wherein the at least one secondary pack comprises at least two primary packs (210), each comprising a plurality of compressible ceiling tiles (212) and a first securing member (260), and a second securing member (250). The ceiling tiles of each primary pack are compressed along a compression axis (C) to a compressed state and secured in the compressed state by means of the first securing member, wherein the at least two primary packs are stacked along the compression axis. The second securing member is arranged to at least partly enclose the at least two primary packs in order to counteract an expansion of any of the at least two primary packs from the compressed state in the event of failure of the first securing member associated thereto. There is also disclosed a method for providing such a transport unit.
B65D 71/00 - Bundles of articles held together by packaging elements for convenience of storage or transport, e.g. portable segregating carrier for plural receptacles such as beer cans or pop bottlesBales of material
B65D 85/46 - Containers, packaging elements or packages, specially adapted for particular articles or materials for articles particularly sensitive to damage by shock or pressure for bricks, tiles or building blocks
B65D 85/62 - Containers, packaging elements or packages, specially adapted for particular articles or materials for stacks of articlesContainers, packaging elements or packages, specially adapted for particular articles or materials for special arrangements of groups of articles
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
Packing, stopping and insulating materials; materials made of mineral wool, glass wool, fibre glass, glass fibres and rock fibres; mineral wool, glass wool, fibre glass, glass fibres and rock fibres for insulation, sound proofing and sound absorption; sound proofing materials; sound absorbing materials; insulating, sound proofing and sound absorbing materials in the form of panels and slabs with or without facing; insulating, sound proofing and sound absorption tape and band; metal foils for insulation, sound proofing and sound absorption; mineral wool, glass wool, fibre glass, glass fibres and rock fibres fabrics and paint for insulating, sound proofing and sound absorbing materials; coating materials for insulation, sound proofing and sound absorbing purposes; coating materials for insulating, sound proofing and sound absorbing purposes; products made of semi-processed plastics. Non-metallic building materials, including building panels, building tiles, building slabs, ceilings, ceiling tiles, panels and slabs, wall panels, slabs and tiles, claddings, linings and coatings for walls and ceilings in buildings; facings for building materials; partitions not of metal; non-metallic latticework, runners, hangers, profiles, trims, splices and clips for suspended ceilings and walls; parts and fittings for all aforesaid goods, not included in other classes; building materials for coating walls and ceilings (other than paint); non-metallic coating materials (other than paints).
89.
METHODS AND TILE FOR USE IN A FALSE CEILING OR WALL AND A FALSE CEILING OR WALL
The disclosure relates to a method of preparing an installation, to a method of installation of a false ceiling or wall, to a tile for use in such a false ceiling or wall and to a false ceiling or false wall. The method of preparing an installation comprises: calculating (202) format, position and orientation for each individual tile in the suspended ceiling or wall, associating (202; 206) each individual tile with a unique tile identity, producing (300) the individual tiles according to the calculated format, providing (301) respective tile with the tile identity of respective tile, providing (302) a representation of the suspended ceiling or wall including an association of the position of respective tile with respective tile identity.
The present invention concerns a sound absorbing module (2) for a suspended ceiling (1), comprising a sound absorbent element (6) and a front cover (7). Said front cover (7) is arranged at a distance from the sound absorbent element (6), and according to the present invention the front cover (7) has a flow resistance within the range of 200 to 800 Pas/m. The present invention further concerns a suspended ceiling (1) comprising said sound absorbing module (2).
E04B 9/00 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
E04B 9/30 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by edge details of the ceiling, e.g. securing to an adjacent wall
B32B 9/04 - Layered products essentially comprising a particular substance not covered by groups comprising such substance as the main or only constituent of a layer, next to another layer of a specific substance
B32B 17/06 - Layered products essentially comprising sheet glass, or fibres of glass, slag or the like comprising glass as the main or only constituent of a layer, next to another layer of a specific substance
06 - Common metals and ores; objects made of metal
Goods & Services
Lattices, frames, trellis, gliders, pendants, profiles,
crossover beams, connectors and couplings and clips, made of
metal for suspended ceilings and walls.
92.
A SUSPENDED CEILING SYSTEM AND A METHOD FOR MOUNTING A SUSPENDED CEILING
The present invention relates to a suspended ceiling system (1) comprising a grid of profiles (3) comprising at least one runner (12) each being provided with a plurality of defined fixing points(30), the grid of profiles (3) being suspended in a ceiling structure (11) by means of pressure resistant suspension members (13) in order to sustain upwardly directed loads; a ceiling panel (10, 10a, 10b) provided with one or more attachment structures fixed to a rear surface of the ceiling panel, and at least one attachment point in said one or more attachment structures; and one connection member (20) for each attachment point (52); wherein each connection member (20) is connected to a selected one of said defined fixing points; and wherein each of the connection members (20) comprises a lock arranged to releasably connect to one of the at least one attachment points (52) of said ceiling panel (10, 10a, 10b) in response to the attachment point (52) being pushed in an upward direction towards the lock; whereby the ceiling panel (10, 10a, 10b) is suspended by said at least one runner (12). The present invention further relates to a method for mounting such a suspended ceiling.
E04B 9/00 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation
E04B 9/06 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by constructional features of the supporting construction
E04B 9/20 - Means for suspending the supporting construction adjustable
E04B 9/22 - Connection of slabs, sheets or the like to the supporting construction
E04B 9/26 - Connection of slabs, sheets or the like to the supporting construction with the slabs, sheets or the like positioned on, or held against, horizontal flanges of the supporting construction by means of snap action of elastically deformable elements
The present invention relates to a suspended ceiling system (100, 500) for a room having a structural ceiling. The system(100, 500)comprising: a body unit (108a-e, 208a-c, 308, 508a-c, 608 a-c) attachable to said structural ceiling, at least two string like suspension members (104a-e, 204a-c, 304, 404, 504a-c, 604a-c), such as a wire, a line, a cable, a cord, a thread, and a ceiling tile (102a-e, 402, 502a-c) with sound absorbing properties. Each string like suspension member (104a-e, 204a-c, 304, 404, 504a-c, 604a-c) is attachable to said ceiling tile (102a-e, 402, 502a-c) at two attachment points (106a-e, 406). Said ceiling tile (102a-e, 402, 502a-c) is suspendable in said body unit(108a-e, 208a-c, 308, 508a-c, 608 a-c) by means of said at least two string like suspension members (104a-e, 204a-c, 304, 404, 504a-c, 604a-c). Said body unit (108a-e, 208a-c, 308, 508a-c, 608 a-c) for each of said at least two string like suspension members (104a-e, 204a-c, 304, 404, 504a-c, 604a-c) defines a suspension member receiving path (205a-c, 305) for reception thereof. The present invention also relates to a corresponding method.
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
20 - Furniture and decorative products
Goods & Services
Sounds and/or heat insulating materials; insulating
materials made of mineral wool; glass fibres and rock fibres
for insulation; insulating materials in the form of panels
and slabs with or without facing; insulating tape and band;
metal foils for insulation; fiberglass fabrics and paint for
insulating purposes; acoustic screens (terms considered too
vague by the International Bureau - rule 13.2.b) of the
Common Regulations; parts, fittings and accessories for all
aforesaid goods, not included in other classes. Non-metallic building materials, including building panels,
building tiles, building slabs, ceilings, ceiling tiles,
panels and slabs, wall panels, slabs and tiles, claddings,
linings and coatings for walls and ceilings in buildings;
facings for building materials; partitions not of metal;
non-metallic latticework, runners, hangers, profiles, trims,
splices and clips for ceilings and walls (terms considered
too vague by the International Bureau - rule 13.2.b) of the
Common Regulations; screens (building material, not of
metal); parts, fittings and accessories for all aforesaid
goods, not included in other classes. Furniture, including screens.
95.
SOUND ABSORBING MODULE AND A SUSPENDED CEILING COMPRISING THE SAME
The present invention concerns a sound absorbing module (2) for a suspended ceiling (1), comprising a sound absorbent element (6) and a front cover (7). Said front cover (7) is arranged at a distance from the sound absorbent element (6), and according to the present invention the front cover (7) has a flow resistance within the range of 200 to 800 Pas/m. The present invention further concerns a suspended ceiling (1) comprising said sound absorbing module (2).
E04B 9/00 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation
E04B 9/30 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation characterised by edge details of the ceiling, e.g. securing to an adjacent wall
E04B 9/04 - CeilingsConstruction of ceilings, e.g. false ceilingsCeiling construction with regard to insulation comprising slabs, sheets or the like
41 - Education, entertainment, sporting and cultural services
Goods & Services
Business information services provided online from the internet. Online electronic publishing of catalogues, periodicals and broschures; providing publications, catalogues, periodiclas and catalogues from the internet which may be downloaded or browsed; providing online publications, catalogues, periodicals and broschures.
41 - Education, entertainment, sporting and cultural services
Goods & Services
Business information services provided online from the internet. Online electronic publishing of catalogues, periodicals and broschures; providing publications, catalogues, periodiclas and catalogues from the internet which may be downloaded or browsed; providing online publications, catalogues, periodicals and broschures.
06 - Common metals and ores; objects made of metal
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
Metal building materials; Ceilings of metal, building boards, panels, plates and tiles of metal; Wall claddings, coverings and linings of metal for walls (buildings); Grid systems of metal for ceilings; Suspension systems of metal for ceilings; Grids, rails, hangers, profile sections, cornices, joints and clips of metal for ceilings and walls; Parts and fittings for all the aforesaid goods (not included in other classes ). Sound- and/or heat-insulating materials; Insulating material made of mineral wool, glass fibres and rock fibres; Insulating material in the form of panels and tiles, with or without facing; Insulating tape and band; Metal foils for insulation; Fibreglass textiles and paint for insulation purposes; Acoustic screens; Parts, components and accessories for all the aforesaid goods, not included in other classes. Building materials (non-metallic), including building panels, building bricks, building boards, ceilings, ceiling tiles, boards and slabs, wall panels, slabs and quarry tiles, cladding; Claddings, linings and coatings for walls and ceilings in buildings; Surfaces and cladding for building materials; Partitions (not of metal), non-metallic grids, rails, hangers, profile sections, cornices, joints and clips for ceilings and walls; Screens (building materials, not of metal); Parts, components and accessories for all the aforesaid goods, not included in other classes.
06 - Common metals and ores; objects made of metal
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
Metal building materials; Ceilings of metal, building boards, panels, plates and tiles of metal; Wall claddings, coverings and linings of metal for walls (buildings); Grid systems of metal for ceilings; Suspension systems of metal for ceilings; Grids, rails, hangers, profile sections, cornices, joints and clips of metal for ceilings and walls; Parts and fittings for all the aforesaid goods (not included in other classes ). Sound- and/or heat-insulating materials; Insulating material made of mineral wool, glass fibres and rock fibres; Insulating material in the form of panels and tiles, with or without facing; Insulating tape and band; Metal foils for insulation; Fibreglass textiles and paint for insulation purposes; Acoustic screens; Parts, components and accessories for all the aforesaid goods, not included in other classes. Building materials (non-metallic), including building panels, building bricks, building boards, ceilings, ceiling tiles, boards and slabs, wall panels, slabs and quarry tiles, cladding; Claddings, linings and coatings for walls and ceilings in buildings; Surfaces and cladding for building materials; Partitions (not of metal), non-metallic grids, rails, hangers, profile sections, cornices, joints and clips for ceilings and walls; Screens (building materials, not of metal); Parts, components and accessories for all the aforesaid goods, not included in other classes.
06 - Common metals and ores; objects made of metal
17 - Rubber and plastic; packing and insulating materials
19 - Non-metallic building materials
Goods & Services
Metal building materials; Ceilings of metal, building boards, panels, plates and tiles of metal; Wall claddings, coverings and linings of metal for walls (buildings); Grid systems of metal for ceilings; Suspension systems of metal for ceilings; Grids, rails, hangers, profile sections, cornices, joints and clips of metal for ceilings and walls; Parts and fittings for all the aforesaid goods (not included in other classes ). Sound- and/or heat-insulating materials; Insulating material made of mineral wool, glass fibres and rock fibres; Insulating material in the form of panels and tiles, with or without facing; Insulating tape and band; Metal foils for insulation; Fibreglass textiles and paint for insulation purposes; Acoustic screens; Parts, components and accessories for all the aforesaid goods, not included in other classes. Building materials (non-metallic), including building panels, building bricks, building boards, ceilings, ceiling tiles, boards and slabs, wall panels, slabs and quarry tiles, cladding; Claddings, linings and coatings for walls and ceilings in buildings; Surfaces and cladding for building materials; Partitions (not of metal), non-metallic grids, rails, hangers, profile sections, cornices, joints and clips for ceilings and walls; Screens (building materials, not of metal); Parts, components and accessories for all the aforesaid goods, not included in other classes.
