A glazed façade anchoring system to a building including a box with a connection system to the façade and connection to the building slab. The first and second connections enable relative movement between one another, when the façade moves within the gap between the rear surface of the façade and the building slab edge under the high pressure loads due to exceptional events such as explosions. The device includes one or more solid elements with dissipative components acting in compression in the inward building direction and one or more solid elements with dissipative components acting in compression in the outward building direction.
E04H 9/04 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate against air-raid or other war-like actions
E06B 5/10 - Doors, windows, or like closures for special purposesBorder constructions therefor for protection against air-raid or other war-like actionDoors, windows, or like closures for special purposesBorder constructions therefor for other protective purposes
The dynamic vibration damping system for a building, comprises damping units inserted in housings located in the building façades, or slabs, or partition walls. The damping units comprise a swinging mass (2) sliding horizontally in opposite directions on a swinging plane parallel to the façade or to the slab or to the partition wall when the building vibrates, horizontal springs (3) to absorb the energy generated by the movements of the swinging mass (2), and dampers (4) to damp movements of the swinging mass (2).
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
E04B 1/98 - Protection against other undesired influences or dangers against vibrations or shocksProtection against other undesired influences or dangers against mechanical destruction, e.g. by air-raids
F16F 7/10 - Vibration-dampersShock-absorbers using inertia effect
F16F 7/116 - Vibration-dampersShock-absorbers using inertia effect the inertia member being resiliently mounted on metal springs
3.
DISSIPATIVE BRACKET TO MITIGATE EFFECTS OF EXPLOSIONS ON BUILDING FACADES
A glazed façade anchoring system to a building including a box with a connection system to the façade and connection to the building slab. The first and second connections enable relative movement between one another, when the façade moves within the gap between the rear surface of the façade and the building slab edge under the high pressure loads due to exceptional events such as explosions. The device includes one or more solid elements with dissipative components acting in compression in the inward building direction and one or more solid elements with dissipative components acting in compression in the outward building direction.
E06B 5/10 - Doors, windows, or like closures for special purposesBorder constructions therefor for protection against air-raid or other war-like actionDoors, windows, or like closures for special purposesBorder constructions therefor for other protective purposes
A window frame (100) comprises a primary frame (1) fixed to a building structure, a secondary frame (2), fixed to the primary frame (1) by means of ironmongery that allow opening and closing movements of the secondary frame (2) in respect of the primary frame (1). The primary frame (1) comprises at least four primary profiles (21, 22, 23, 24) each comprising a primary first profiled bar (4) in aluminum, having one side on the outside of the primary frame (1), a primary second profiled bar (5) in composite material, fixed transversally to the first primary profiled bar (4) and a primary first sealing gasket (6) fixed to the primary first profiled bar (4), a primary second sealing gasket (7) fixed to the primary second profiled bar (5). The secondary frame (2) comprises at least four secondary profiles (31, 32, 33, 34), each comprising one secondary first profiled bar (27) in aluminum, having a side facing the inside of the window, and having an edge that defines the outermost perimeter of the primary frame (1), a secondary second profiled bar (28) in composite material fixed to the secondary first profile bar (27) to support one side of a glass pane (3) held in place by means of one retainer (36) able to be adjusted according to the thickness of the glass pane (3), a first and a second secondary seal (29, 30) fixed to the secondary first profile bar (27) and a sealing gasket (35) between the glass pane (3) and the retainer (36).
The dynamic vibration damping system for a building, comprises damping units inserted in housings located in the building façades, or slabs, or partition walls. The damping units comprise a swinging mass (2) sliding horizontally in opposite directions on a swinging plane parallel to the façade or to the slab or to the partition wall when the building vibrates, horizontal springs (3) to absorb the energy generated by the movements of the swinging mass (2), and dampers (4) to damp movements of the swinging mass (2).
E04B 1/98 - Protection against other undesired influences or dangers against vibrations or shocksProtection against other undesired influences or dangers against mechanical destruction, e.g. by air-raids
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
The dynamic vibration damping system for a building, comprises damping units inserted in housings located in the building façades, or slabs, or partition walls. The damping units comprise a swinging mass (2) sliding horizontally in opposite directions on a swinging plane parallel to the façade or to the slab or to the partition wall when the building vibrates, horizontal springs (3) to absorb the energy generated by the movements of the swinging mass (2), and dampers (4) to damp movements of the swinging mass (2).
E04H 9/02 - Buildings, groups of buildings or shelters adapted to withstand or provide protection against abnormal external influences, e.g. war-like action, earthquake or extreme climate withstanding earthquake or sinking of ground
E04B 1/98 - Protection against other undesired influences or dangers against vibrations or shocksProtection against other undesired influences or dangers against mechanical destruction, e.g. by air-raids
The invention relates to a fastening anchor for facades, comprising at least one deformation section that undergoes a predetermined plastic deformation in the event of a tensile and/or pressure load in order to absorb energy, wherein the deformation section (120) has a plurality of ribs (122, 123) separated from one another by recesses (124), wherein at least one first rib (122) is configured to have an effect both in the event of a pressure load as well as a tensile load and at least one second rib (123) is configured to have an effect only in the event of a pressure load or only in the event of a tensile load.
E04F 13/08 - Coverings or linings, e.g. for walls or ceilings composed of covering or lining elementsSub-structures thereforFastening means therefor composed of a plurality of similar covering or lining elements
9.
PANEL PARTICULARLY FOR PROVIDING EXPLOSION-RESISTANT CURTAIN WALLS
A panel, particularly for providing explosion-resistant curtain walls, comprising one or more glass panes, so as to form a glazing unit, which are associated with a supporting frame constituted by at least two uprights which are connected, at their upper and lower ends, by at least two cross-- members. The panel comprises first means for strengthening and interconnecting the uprights and the cross-members, and second means for strengthening and guiding the mutual position of two contiguous uprights of two panels arranged one above the other are associated with the uprights. The panel further has third means for limiting the mutual rotation of two contiguous uprights of two panels arranged side by side.
06 - Common metals and ores; objects made of metal
11 - Environmental control apparatus
19 - Non-metallic building materials
37 - Construction and mining; installation and repair services
Goods & Services
(1) Metal coverings for facades and exterior and interior walls of buildings, civil engineering buildings of metal, industrial floors of metal, frames of metal for windows.
(2) Air conditioners, air conditioning units, dispensing units for room air fresheners, ceiling fans, water coolers, air distribution diffusers, ventilating fans for commercial and industrial use, electric lighting fixtures, water conditioning units.
(3) Facades and exterior and interior walls of buildings, industrial floors not of metal, stained-glass windows. (1) Constructions of exterior facades for buildings, installation of apparatus for environmental conditioning (services for others).
06 - Common metals and ores; objects made of metal
07 - Machines and machine tools
19 - Non-metallic building materials
27 - Floor and wall coverings
Goods & Services
metal goods, namely, wall lining panels and facade panels; structural steelwork parts of buildings, namely, wall panels, external curtain walls or cladding for construction and building, interior wall partitions or cladding for construction and building, shower, bathtub and toilet partitions and stalls machinery, namely, air brushes for applying coloring and the like; compressors for machines, air conditioners or refrigerators; industrial robots, washing machines for washing internal or external curtain walls, power washing machines non-metallic building materials, namely, structural building elements, namely, ceiling panes, floor panels, and wall partitions, non-insulating wall lining panels, and facade panels, doors, door frames, window frames, wall panels, shower, bathtub and toilet partitions and stalls, external curtain walls or cladding for construction and building, interior wall partitions, or cladding for construction and building, all in glass, granite or other non-metallic materials floor coverings, namely, underlays for carpeting in the nature of carpet padding
06 - Common metals and ores; objects made of metal
11 - Environmental control apparatus
19 - Non-metallic building materials
37 - Construction and mining; installation and repair services
Goods & Services
Metal coverings for facades and exterior and interior walls of buildings, civil-engineering works of metal, industrial floors of metal, frames of metal for windows. Apparatus for refrigerating, ventilating, water supply, lighting. Facades and exterior and interior walls of buildings, industrial floors, not of metal, stained-glass windows. Construction of exterior facades for buildings and installation of apparatus for air conditioning (services for others).
06 - Common metals and ores; objects made of metal
19 - Non-metallic building materials
37 - Construction and mining; installation and repair services
42 - Scientific, technological and industrial services, research and design
Goods & Services
(1) Prefabricated structural building components namely, interior and external walls, floors, ceilings and roofs all of which are used in the constructions of all types of retail buildings and complexes, commercial buildings and complexes, and civic buildings and complexes and wherein the prefabricated structural building components contain all of the necessary heating, air-conditioning, electrical, plumbing, and mechanical systems as well as all specified interior and exterior surface finishings, namely, metal interior and external walls, metal floors, metal ceilings, and metal roofs.
(2) Prefabricated structural building components namely, interior and external walls, floors, ceilings and roofs all of which are used in the constructions of all types of retail buildings and complexes, commercial buildings and complexes, and civic buildings and complexes and wherein the prefabricated structural building components contain all of the necessary heating, air-conditioning, electrical, plumbing, and mechanical systems as well as all specified interior and exterior surface finishings, namely, non-metallic interior and external walls, non-metallic floors, non-metallic ceilings, and non-metallic roofs. (1) Design and construction of all types of retail buildings and complexes, commercial buildings and complexes, and civic buildings and complexes, the said services including the provision of all required architectural services, interior and exterior design services, mechanical, structural, electrical and design engineering services, namely, building construction, repair, and installation services.
(2) Design and construction of all types of retail buildings and complexes, commercial buildings and complexes, and civic buildings and complexes, the said services including the provision of all required architectural services, interior and exterior design services, mechanical, structural, electrical and design engineering services, namely, architectural design, interior and exterior design, and engineering services.
06 - Common metals and ores; objects made of metal
19 - Non-metallic building materials
37 - Construction and mining; installation and repair services
41 - Education, entertainment, sporting and cultural services
42 - Scientific, technological and industrial services, research and design
Goods & Services
metal goods; namely, structural steelwork; ceilings; floors and partitions; wall linings and facades; doors; door frames; window frames; windows; ceiling systems comprising panels; couplings and joints; fencing panels; flooring; gates; metal window shutters; metal rolling window shutters; metal roofing panels; tables; external curtain wall in metal; permanent interior wall partitions non-metallic building materials; namely, structural building elements; ceilings; floors and partitions; wall linings and facades; doors; sliding doors; door frames; window frames; fences; glass panels; tiles; windows and window panes; pre-fabricated or modular homes; panelling and wall panels; paving stones; paving and pavement tiles; shutters; skylights; wall tiles; wallboards; external curtain wall in glass, granite or other non-metallic materials; permanent interior wall partitions construction and repair services; namely, construction, maintenance and repair of buildings education services; namely, organizing and conducting competitions relating to the building trade; publication of books, pamphlets and magazines for the development of the mental facility of people in the building trade miscellaneous services; namely, civil engineering services
